124 Before You Begin
4 Pull the cable connector from the card connector.
NOTICE: Be careful when removing the card to avoid damaging the card, card cable, or surrounding components.
Coin-Cell Battery
CAUTION: Before performing the following procedures, follow the safety instructions in your Product
Information Guide.
NOTICE: To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by periodically
touching a connector on the back panel of the computer.
NOTICE: To prevent damage to the system board, remove the main battery before you service the computer.
1 Follow the procedures in "Before You Begin" on page 109.
2 On the bottom of the computer, loosen the captive screw on the memory module/coin-cell battery
cover and remove the cover (see "Bottom View" on page 23).
1 metal tab 2 card 3 cable connector
1 card 2 card connector 3 cable connector
3
2
1

Dell Latitude D531 Specifications

General

Hard Drive Interface	SATA
Processor	AMD Turion 64 X2 or AMD Sempron
RAM	Up to 4GB DDR2
Display	15.4-inch WXGA (1280x800) or WXGA+ (1440x900)
Graphics	ATI Radeon X1270
Storage	Up to 160GB HDD
Optical Drive	DVD-ROM, DVD+/-RW
Operating System	Windows Vista, Windows XP
Wireless	Dell Wireless 1390
Ports	4 x USB 2.0, VGA, Ethernet, Modem, Headphone, Microphone
