Dell OptiPlex 745 User Manual


5. Install the new system battery.
a. Support the battery connector by pressing down firmly on the positive side of the connector.
b. Hold the battery with the "+" facing up, and slide it under the securing tabs at the positive side of the connector.
c. Press the battery straight down into the connector until it snaps into place.

6. Replace the computer cover (see Replacing the Computer Cover).

7. Enter system setup (see Entering System Setup) and restore the settings you recorded in step1.

8. Properly dispose of the old battery as described in the Product Information Guide.
Back to Contents Page

1
system battery
2
positive side of battery connector
3
battery socket tab
4
battery socket
NOTICE: To avoid damage to the battery connector, you must firmly support the connector while replacing the battery.

Dell OptiPlex 745 Specifications

General

Chipset	Intel Q965 Express
Memory	Up to 8GB DDR2 SDRAM
Form Factor	Mini Tower, Desktop, Small Form Factor, Ultra Small Form Factor
Audio	Integrated High Definition Audio
Power Supply	305W (Mini Tower)
Processor	Intel Core 2 Duo, Pentium D
Graphics	Integrated Intel Graphics Media Accelerator 3000
Networking	Integrated Gigabit Ethernet
Expansion Slots	2 PCI, 1 PCIe x16, 1 PCIe x1
Ports	USB 2.0, Serial, Parallel, RJ-45, Audio jacks
Operating System	Windows XP, Windows Vista
Optical Drive	DVD-ROM, DVD+/-RW
