Dell™OptiPlex™745User'sGuide
Module Bay
Module Bay

You can install a Dell™ portable device such as a floppy drive, optical drive, or second hard drive in the module bay.
Your Dell computer ships with either an optical drive or an airbay (filler blank) installed in the module bay. You can secure a device in the module bay by two
methods:
l Locking switch (accessed by removing the computer cover)
l Device screw (packaged separately)
See Securing a Device in the Module Bay for more information about securing a device in your computer.

Installing a Device When Your Computer Is Turned Off
To install a device in the module bay:

1. If the module bay contains an airbay instead of a device, pull the airbay out of the module bay and skip to step 5. If the airbay is locked, remove the
device screw.

2. If the module bay contains a device that is locked, remove the cover (see Removing the Computer Cover) and move the module locking switch to the
unlocked position by raising the locking switch. If a device screw is used, remove the screw.
CAUTION: Before you begin any of the procedures in this section, follow the safety instructions in the Product Information Guide.
NOTICE: To prevent damage to devices, place them in a safe, dry place when they are not installed in the computer. Avoid pressing down on them or
placing heavy objects on top of them.
1
bottom of computer
2
device screw

Dell OptiPlex 745 Specifications

General

Chipset	Intel Q965 Express
Memory	Up to 8GB DDR2 SDRAM
Form Factor	Mini Tower, Desktop, Small Form Factor, Ultra Small Form Factor
Audio	Integrated High Definition Audio
Power Supply	305W (Mini Tower)
Processor	Intel Core 2 Duo, Pentium D
Graphics	Integrated Intel Graphics Media Accelerator 3000
Networking	Integrated Gigabit Ethernet
Expansion Slots	2 PCI, 1 PCIe x16, 1 PCIe x1
Ports	USB 2.0, Serial, Parallel, RJ-45, Audio jacks
Operating System	Windows XP, Windows Vista
Optical Drive	DVD-ROM, DVD+/-RW
