Figure 51. Removing the speakers
Steps
Lift the left and right speakers, along with the cables off the palm rest and keyboard assembly.
Installing the speakers
CAUTION: The information in this installation section is intended for authorized service technicians only.
Prerequisites
If you are replacing a component, remove the existing component before performing the installation process.
About this task
The following image(s) indicate the location of the speakers and provides a visual representation of the installation procedure.
72
Removing and installing Field Replaceable Units (FRUs)
