Tent
Figure 10. Tent mode
Battery charge and status light
The following table lists the battery charge and status light behavior of your Latitude 9450 2-in-1.
Table 1.
Battery charge and status light behavior
Power Source LED Behavior System Power State Battery Charge Level
AC Adapter Off S0 - S5 Fully Charged
AC Adapter Solid White S0 - S5 < Fully Charged
Battery Off S0 - S5 11-100%
Battery Solid Amber (590+/-3 nm) S0 - S5 < 10%
● S0 (ON) - System is turned on.
● S4 (Hibernate) - The system consumes the least power compared to all other sleep states. The system is almost at an OFF
state, except for a trickle power. The context data is written to a hard drive.
● S5 (OFF) - The system is in a shutdown state.
Views of Latitude 9450 2-in-1
13
