Dell P166G User Manual

Views of Latitude 9450 2-in-1
Right
Figure 1. Right view
1. Universal audio port
Connect headphones or a headset (headphone and microphone combo).
2. Thunderbolt 4.0 with DisplayPort Alt Mode/USB Type-C/USB4/Power Delivery
Supports USB4, DisplayPort 2.1, Thunderbolt 4 and also enables you to connect to an external display using a display adapter.
Provides data transfer rates of up to 40 Gbps for USB4 and Thunderbolt 4.
NOTE:
You can connect a Dell Docking Station to the Thunderbolt 4 ports. For more information, search in the
Knowledge Base Resource at www.dell.com/support.
NOTE: A USB Type-C to DisplayPort adapter (sold separately) is required to connect a DisplayPort device.
NOTE: USB4 is backward compatible with USB 3.2, USB 2.0, and Thunderbolt 3.
NOTE: Thunderbolt 4 supports two 4K displays or one 8K display.
3. Wedge-shaped lock slot
Connect a security cable to prevent unauthorized movement of your computer.
Left
Figure 2. Left view
1. Thunderbolt 4.0 with DisplayPort Alt Mode/USB Type-C/USB4/Power Delivery
1
6 Views of Latitude 9450 2-in-1

Dell P166G Specifications

General

Brand	Dell
Model	P166G
Category	Laptop
Language	English
