Figure 47. Disconnecting the display cable
5. Open the display assembly to a 90-degree angle and lay the computer on the edge of the table so the palm-rest assembly is
laying flat on the table and the display assembly is over the edge.
6. Remove the six (M2.5x4) screws that secure the display assembly to the computer.
7. Press the edges of the system near the hinges, and lift the hinges in the upward direction away from the computer.
8. Lift the display assembly off the computer.
NOTE:
The display assembly is a Hinge-Up Design (HUD) assembly and it cannot be further disassembled once it is
removed from the bottom chassis. If any components in the display assembly are malfunctioning and must be replaced,
replace the entire display assembly.
Installing the display assembly
CAUTION: The information in this installation section is intended for authorized service technicians only.
Prerequisites
If you are replacing a component, remove the existing component before performing the installation procedure.
About this task
The following images indicate the location of the display assembly and provide a visual representation of the installation
procedure.
Removing and installing Field Replaceable Units (FRUs)
67
