Installing camera
1. Place the camera on the display back cover .
2. Connect the camera cable to the connector on the display assembly.
3. Install the:
a. display panel
b. display bezel
c. display assembly
d. battery
e. base cover
4. Follow the procedure in After working inside your computer
Display hinges
Removing display hinges
1. Follow the procedure in Before working inside your computer.
2.
NOTE: When replacing the display cable onto the display back- cover of the Latitude 3190, on-site technicians must
first disconnect the cable from the camera module, and carefully peel back the pieces of aluminum foil securing the
display cable to the display back-cover, and then re-adhere the foil after replacing the display cable, as indicated in the
image below.
NOTE: Technicians should note that the display hinges, display cable, and camera are also separate service parts that
can be individually replaced
Remove the:
a. base cover
b. battery
c. display assembly
d. display bezel
e. display panel
3. To remove display hinges:
a. Remove the four M2.5x2.5 screws that secure the display hinges to the display back cover [1].
b. Lift the display hinges from the display back cover [2].
Disassembly and reassembly
49
