Installing display hinges
1. Place the display hinges on the display back cover.
2. Replace the four M2.5x2.5 screws to secure the display hinges to the display back cover. .
3. Install the:
a. display panel
b. display bezel
c. display assembly
d. battery
e. base cover
4. Follow the procedure in After working inside your computer
Palm rest
Replacing palm rest
1. Follow the procedure in Before working inside your computer.
2. Remove the:
a. base cover
b. battery
c. keyboard
d. system board
e. Solid State Drive card
f. audio
g. power connector
h. coin cell battery
i. speaker
j. display assembly
NOTE:
50 Disassembly and reassembly
