Replacing the battery
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Procedure
1. Using the alignment posts, place the battery on the palm-rest assembly.
2. Replace the four screws (M2x3) that secure the battery to the palm-rest assembly.
3. Route the speaker cable through the routing guides on the battery.
4. Connect the battery cable to the system board.
9
Replacing the battery 21
