Replacing the coin-cell battery
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Procedure
1. Adhere the coin-cell battery to the palm-rest assembly.
2. Route the coin-cell battery cable under the I/O-board cable.
3. Connect the coin-cell battery cable to the system board.
Post-requisites
1. Replace the fan.
2. Replace the base cover.
13
Replacing the coin-cell battery 29
