Replacing the speakers
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow
the steps in Before working inside your computer. After working inside your computer, follow the instructions in After
working inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Procedure
1. Using the alignment posts on the palm-rest assembly, place the speakers on the palm-rest assembly.
2. Route the speaker cable through the routing guides on the battery and palm-rest assembly.
3. Connect the speaker cable to the system board.
Post-requisites
Replace the base cover.
17
34 Replacing the speakers
