Dell POWEREDGE R710 User Manual

100 Installing System Components
Installing the Cooling Shroud
1 Align the tabs on the right side of the cooling shroud with the cutouts in
the right chassis wall.
2 Lower the right end of the shroud into the chassis cutouts and rotate the
left end down inside the left chassis wall.
3 Close the system. See "Closing the System."
4 Reconnect the system to the electrical outlet and turn on the system and
attached peripherals.
Cooling Fans
The system has either five or four hot-swappable fans to provide cooling to
the system’s interior components.
• Dual-processor configurations have five fans.
• Single-processor configurations have four fans (fans 1 through 4) and a
blank inserted in the fan 5 bay. Fan 5 can be installed as an optional fan.
NOTE: In the event of a problem with a particular fan, the fan’s number is
referenced by the system’s management software, allowing you to easily identify
and replace the proper fan.
Removing a Cooling Fan
CAUTION: Many repairs may only be done by a certified service technician. You
should only perform troubleshooting and simple repairs as authorized in your
product documentation, or as directed by the online or telephone service and
support team. Damage due to servicing that is not authorized by Dell is not covered
by your warranty. Read and follow the safety instructions that came with the
product.
CAUTION: The cooling fans are hot-swappable. To maintain proper cooling while
the system is on, replace only one fan at a time.
CAUTION: On single-processor systems using four fans, the fan blank must be
installed in the FAN5 bay to maintain proper cooling while the system is on.
NOTE: If a fan is installed in FAN5 in a single-processor configuration, the fan will
still be operational, however the fan will not appear in the iDRAC user interface
unless the fan was installed before the system was started.
1 Open the system. See "Opening the System."

Dell POWEREDGE R710 Specifications

General

Tcase	76 °C
Bus type	QPI
Stepping	D0
FSB Parity	No
Processor code	SLBF7
Processor cache	8 MB
Processor cores	4
Processor model	E5530
System bus rate	5.86 GT/s
Processor series	Intel Xeon 5500 Series
Processor socket	Socket B (LGA 1366)
Processor threads	8
Processor codename	Nehalem EP
Motherboard chipset	Intel® 5520
Number of QPI links	2
Processing Die size	263 mm²
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor lithography	45 nm
Processor system type	DP
Processor manufacturer	Intel
Processor package size	42.5 x 45 mm
Processor front side bus	- MHz
Processor boost frequency	2.66 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	80 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	18
Memory types supported by processor	DDR3-SDRAM
Number of Processing Die Transistors	731 M
Memory channels supported by processor	Triple
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	144 GB
HDD size	3.5 \
HDD capacity	146 GB
HDD interface	Serial Attached SCSI (SAS)
Optical drive type	DVD-ROM
Total storage capacity	292 GB
Maximum storage capacity	6 TB
Internal memory	12 GB
Memory clock speed	1066 MHz
Memory layout (slots x size)	6 x 2 GB
Graphics card	G200
Dimensions (WxDxH)	443.1 x 680.7 x 86.4 mm
Non-operating relative humidity (non-condensing)	5 - 95 %
PS/2 ports quantity	0
USB 2.0 ports quantity	5
Power supply	570 W
Power requirements	90 - 264V
Compatible operating systems	Windows Server, Standart Business Server, Novell SUSE Linux, Red Hat Linux Enterprise
Chassis type	Rack (2U)
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Networking features	Gigabit Ethernet
Processor ARK ID	37103
Intel® Turbo Boost Technology	1.0

Weight and Dimensions

Depth	680.7 mm
Width	443.1 mm
Height	86.4 mm
Weight	26100 g
