Dell POWEREDGE R710 User Manual

64 Using the System Setup Program and UEFI Boot Manager
Embedded Server Management Screen
Serial Port Address
(Serial Device 1=COM1,
Serial Device2=COM2
default)
Sets the serial port addresses for the two serial devices.
NOTE: Only Serial Device 2 can be used for Serial Over
LAN (SOL). To use console redirection by SOL, configure
the same port address for console redirection and the
serial device.
External Serial Connector Specifies whether Serial Device 1, Serial Device 2, or
Remote Access Device has access to the external serial
connector.
NOTE: Only Serial Device 2 can be used for Serial Over
LAN (SOL). To use console redirection by SOL, configure
the same port address for console redirection and the
serial device.
Failsafe Baud Rate
(115200 default)
Displays the failsafe baud rate used for console
redirection. BIOS attempts to determine the baud rate
automatically. This failsafe baud rate is used only if the
attempt fails. This rate should not be adjusted.
Remote Terminal Type
(VT 100/VT220 default)
Sets the remote console terminal type, either
VT100/VT220 or ANSI.
Redirection After Boot
(Enabled default)
Enables or disables BIOS console redirection when the
operating system is loaded.
Option Description
Front Panel LCD Options Options are User Defined String, Model Number, or
None.
If the LCD Home screen is set to an option other than
these three choices, the option will be displayed as
"Advanced" in the BIOS. In this event, the option cannot
be changed in the BIOS unless it is changed back to User
Defined String, Model Number, or None through
another LCD configuration utility (such as the iDRAC
Configuration Utility or the LCD panel menu).
User-Defined LCD String You can enter a name or other identifier for the system, to
be displayed on the LCD module screen.
Option Description

Dell POWEREDGE R710 Specifications

General

Tcase	76 °C
Bus type	QPI
Stepping	D0
FSB Parity	No
Processor code	SLBF7
Processor cache	8 MB
Processor cores	4
Processor model	E5530
System bus rate	5.86 GT/s
Processor series	Intel Xeon 5500 Series
Processor socket	Socket B (LGA 1366)
Processor threads	8
Processor codename	Nehalem EP
Motherboard chipset	Intel® 5520
Number of QPI links	2
Processing Die size	263 mm²
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor lithography	45 nm
Processor system type	DP
Processor manufacturer	Intel
Processor package size	42.5 x 45 mm
Processor front side bus	- MHz
Processor boost frequency	2.66 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	80 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	18
Memory types supported by processor	DDR3-SDRAM
Number of Processing Die Transistors	731 M
Memory channels supported by processor	Triple
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	144 GB
HDD size	3.5 \
HDD capacity	146 GB
HDD interface	Serial Attached SCSI (SAS)
Optical drive type	DVD-ROM
Total storage capacity	292 GB
Maximum storage capacity	6 TB
Internal memory	12 GB
Memory clock speed	1066 MHz
Memory layout (slots x size)	6 x 2 GB
Graphics card	G200
Dimensions (WxDxH)	443.1 x 680.7 x 86.4 mm
Non-operating relative humidity (non-condensing)	5 - 95 %
PS/2 ports quantity	0
USB 2.0 ports quantity	5
Power supply	570 W
Power requirements	90 - 264V
Compatible operating systems	Windows Server, Standart Business Server, Novell SUSE Linux, Red Hat Linux Enterprise
Chassis type	Rack (2U)
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Networking features	Gigabit Ethernet
Processor ARK ID	37103
Intel® Turbo Boost Technology	1.0

Weight and Dimensions

Depth	680.7 mm
Width	443.1 mm
Height	86.4 mm
Weight	26100 g
