Troubleshooting Your System 165
11 Reconnect the system to the electrical outlet, and turn on the system and
attached peripherals.
If the problem is not resolved,
see "Getting Help."
Troubleshooting a Tape Backup Unit
CAUTION: Many repairs may only be done by a certified service technician. You
should only perform troubleshooting and simple repairs as authorized in your
product documentation, or as directed by the online or telephone service and
support team. Damage due to servicing that is not authorized by Dell is not covered
by your warranty. Read and follow the safety instructions that came with the
product.
1 Try using a different tape cartridge.
2 Ensure that the device drivers for the tape drive are installed and are
configured correctly. See your tape backup unit documentation for more
information about device drivers.
3 Reinstall the tape-backup software as instructed in the tape-backup
software documentation.
4 For external tape backup units, ensure that the interface cable is fully
connected to the tape device and the external port on the controller card.
5 For a SCSI tape backup unit, verify that the tape device is configured for a
unique SCSI ID number and that the interface cable is properly
terminated.
See the documentation for the tape backup unit for instructions on
selecting the SCSI ID number and terminating the SCSI cable.
6 Run the appropriate online diagnostics tests. See "Using Dell™
PowerEdge™ Diagnostics."
7 Turn off the system and attached peripherals, and disconnect the system
from the electrical outlet.
8 Open the system. See "Opening the System."
9 Check the internal cable and controller connections.
a For SCSI tape devices, reseat the SCSI controller card in the
expansion card slot and ensure that the interface cable is firmly
connected to the SCSI connector.

Dell POWEREDGE R710 Specifications

General

Tcase	76 °C
Bus type	QPI
Stepping	D0
FSB Parity	No
Processor code	SLBF7
Processor cache	8 MB
Processor cores	4
Processor model	E5530
System bus rate	5.86 GT/s
Processor series	Intel Xeon 5500 Series
Processor socket	Socket B (LGA 1366)
Processor threads	8
Processor codename	Nehalem EP
Motherboard chipset	Intel® 5520
Number of QPI links	2
Processing Die size	263 mm²
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor lithography	45 nm
Processor system type	DP
Processor manufacturer	Intel
Processor package size	42.5 x 45 mm
Processor front side bus	- MHz
Processor boost frequency	2.66 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	80 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	18
Memory types supported by processor	DDR3-SDRAM
Number of Processing Die Transistors	731 M
Memory channels supported by processor	Triple
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	144 GB
HDD size	3.5 \
HDD capacity	146 GB
HDD interface	Serial Attached SCSI (SAS)
Optical drive type	DVD-ROM
Total storage capacity	292 GB
Maximum storage capacity	6 TB
Internal memory	12 GB
Memory clock speed	1066 MHz
Memory layout (slots x size)	6 x 2 GB
Graphics card	G200
Dimensions (WxDxH)	443.1 x 680.7 x 86.4 mm
Non-operating relative humidity (non-condensing)	5 - 95 %
PS/2 ports quantity	0
USB 2.0 ports quantity	5
Power supply	570 W
Power requirements	90 - 264V
Compatible operating systems	Windows Server, Standart Business Server, Novell SUSE Linux, Red Hat Linux Enterprise
Chassis type	Rack (2U)
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Networking features	Gigabit Ethernet
Processor ARK ID	37103
Intel® Turbo Boost Technology	1.0

Weight and Dimensions

Depth	680.7 mm
Width	443.1 mm
Height	86.4 mm
Weight	26100 g
