Installing System Components 119
Installing the Cable Retention Bracket
1 Insert the hooks and tabs of the cable retention bracket into the slots in
the chassis wall and slide the bracket back until the latch engages.
2 Install the cooling fan bracket. See "Replacing the Fan Bracket."
3 Install the cooling shroud. See "Installing the Cooling Shroud."
Expansion Cards and Expansion-Card Risers
The system supports up to four PCI Express (PCIe) expansion cards on two
expansion-card risers.
• Expansion-card riser 1 provides two PCIe x4-link Gen 2 expansion slots.
• Expansion-card riser 2 is offered in two versions:
– The standard expansion-card riser 2 provides two
PCIe x8-link Gen 2
expansion slots.
– The optional expansion-card riser 2 provides one PCIe x16-link Gen 2
expansion slot.
CAUTION: Expansion cards can only be plugged into the slots on the expansion-
card risers. Do not plug any expansion cards into the riser connectors on the
system board.
To identify expansion slots, see "Expansion-Card Riser-Board Components
and PCIe Buses."
Expansion Card Installation Guidelines
Observe the following notes and guidelines regarding the expansion-card
slots:
• PCI Express Generation 2 and Generation 1 expansion cards are supported
in all slots.
• In slots 2, 3, and 4, expansion cards can have a maximum length of
24.13
cm (9.5 in). Slot 1 supports a full-length (30.99-cm [12.2-in]) expansion
card.
• The system supports three full-height expansion cards and one low-profile
expansion card (slot 2).
• Although slots 1 and 2 are physically PCIe x8 connectors, they function
only as PCIe x4-link slots.

Dell POWEREDGE R710 Specifications

General

Tcase	76 °C
Bus type	QPI
Stepping	D0
FSB Parity	No
Processor code	SLBF7
Processor cache	8 MB
Processor cores	4
Processor model	E5530
System bus rate	5.86 GT/s
Processor series	Intel Xeon 5500 Series
Processor socket	Socket B (LGA 1366)
Processor threads	8
Processor codename	Nehalem EP
Motherboard chipset	Intel® 5520
Number of QPI links	2
Processing Die size	263 mm²
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor lithography	45 nm
Processor system type	DP
Processor manufacturer	Intel
Processor package size	42.5 x 45 mm
Processor front side bus	- MHz
Processor boost frequency	2.66 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	80 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	18
Memory types supported by processor	DDR3-SDRAM
Number of Processing Die Transistors	731 M
Memory channels supported by processor	Triple
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	144 GB
HDD size	3.5 \
HDD capacity	146 GB
HDD interface	Serial Attached SCSI (SAS)
Optical drive type	DVD-ROM
Total storage capacity	292 GB
Maximum storage capacity	6 TB
Internal memory	12 GB
Memory clock speed	1066 MHz
Memory layout (slots x size)	6 x 2 GB
Graphics card	G200
Dimensions (WxDxH)	443.1 x 680.7 x 86.4 mm
Non-operating relative humidity (non-condensing)	5 - 95 %
PS/2 ports quantity	0
USB 2.0 ports quantity	5
Power supply	570 W
Power requirements	90 - 264V
Compatible operating systems	Windows Server, Standart Business Server, Novell SUSE Linux, Red Hat Linux Enterprise
Chassis type	Rack (2U)
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Networking features	Gigabit Ethernet
Processor ARK ID	37103
Intel® Turbo Boost Technology	1.0

Weight and Dimensions

Depth	680.7 mm
Width	443.1 mm
Height	86.4 mm
Weight	26100 g
