Installing the Keyboard Trim
1. Toe-in the keyboard trim from the front and align it to its original position on the computer. Ensure that the hard-tab
on the left corner snaps into place.
2. Press along the sides of the keyboard trim until it snaps in place.
3. Install the battery.
4. Follow the procedures in
After Working Inside Your Computer
.
Removing the Bluetooth Module
1. Follow the procedures in
Before Working Inside Your Computer
.
2. Remove the:
a) battery
b) keyboard trim
25

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Dell Precision Mobile Workstation M6700 and is the answer not in the manual?

Dell Precision Mobile Workstation M6700 Specifications

General IconGeneral
Display17.3-inch
ProcessorIntel Core i5, i7
GraphicsNVIDIA Quadro K3000M or NVIDIA Quadro K4000M or NVIDIA Quadro K5000M or AMD FirePro M6000
Resolution1920x1080
MemoryUp to 32GB
StorageUp to 750GB HDD, SSD
Optical DriveDVD-ROM, DVD+/-RW, Blu-ray
Operating SystemWindows 7 or Windows 8
Battery9-cell (97Wh)
PortsUSB 3.0, HDMI, DisplayPort, VGA, eSATA
WirelessWi-Fi 802.11 a/b/g/n, Bluetooth
AudioIntegrated speakers, microphone
Camera2MP webcam
