Delta AHCPU560-EN2 Series User Manual

Chapter 8 CIP Object
8-23
8_
 When Instance = 2, the Instance Attributes are listed below.
Instance
Attribute
Name
Access
Rule
Data Type Values
Description
16#01 Interface Speed Get DWORD 16#64
Interface speed currently in use
10(16#0A), 100(16#64), 1000(16#3E8)
Mbps
16#02 Interface Flags Get DWORD 16#F
Ethernet port status, refer to the
following ※1
16#03 Physical Address Get
ARRAY of
6 USINTs
By
Product
MAC address
16#04
Interface Counters
Get
STRUCT
of：
Enthernet interface counter; only
available for AHRTU-ETHN-5A
In Octets
UDINT
16#0
Number of the interface bits received
In Ucast Packets
UDINT 16#0
Number of the interface unicast packets
received
In NUcast Packets
UDINT 16#0
Number of the interface non-unicast
packets received
In Discards
UDINT 16#0
Number of the interface packets
received and then dropped
In Errors
UDINT 16#0
Number of the interface error packets
received
In Inknown Protos
UDINT 16#0
Number of the interface unknown
communication protocol packets
received
Out Octets
UDINT
16#0
Number of the interface bits sent
Out Ucast Packets
UDINT 16#0
Number of the interface unicast packets
sent
Out NUcast Packets
UDINT 16#0
Number of the interface non-unicast
packets sent
Out Discards
UDINT 16#0
Number of the interface packets
received and then dropped
Out Errors
UDINT 16#0
Number of the interface packets
received and then dropped
16#05
Media Counters
Get
STRUCT
of：
16#0
Enthernet interface error
counter; only available for
AHRTU-ETHN-5A
Alignment Errors
UDINT 16#0
The number of times when the
length of the received packet is
not a bit integral
FCS Errors
UDINT 16#0
The number of times when the FCS
error check runs during packet receiving
period
Single Collisions
UDINT 16#0
The number of times when the packet is
sent successfully but with one collision
Multiple Collisions
UDINT 16#0
The number of times when the packet is
sent successfully but with multiple
collisions
SQE Test Errors
UDINT 16#0
The number of times an error message
appears when SQE test runs
Deferred
Transmissions
UDINT 16#0
The number of times when the
transmission is deferred due to
busy interface
Late Collisions
UDINT 16#0
The number of times an collision occurs
during packet sending
Excessive Collisions
UDINT 16#0
The number of times when the packet
cannot be sent due to carrier sense and
excessive collisions occur
MAC Transmit Errors
UDINT 16#0 The number of times when the packet
