Chapter 6 Control Modes of Operation ASDA-B2
6-36 Revision May, 2018
6.4 Torque Mode
Torque control mode (T or Tz) is appropriate in torque control application, such as printing
machine, winding machine, etc. There are two kinds of command source, analog input and
register. Analog command input uses external voltage to control the torque of the motor
while register uses the internal parameters (P1-12 ~ P1-14) as the torque command.
6.4.1 Selection of Torque Command
Torque command source are external analog voltage and parameters. It uses CN1 DI
signal for selection. See as below.
Torque
Command
DI signal of
CN1
Command Source Content Range
TCM1 TCM0
T1 0 0 Mode
T
External analog
signal
Voltage between
T-REF-GND
+/-10V
Tz None Torque command is 0 0
T2 0 1
Parameters
P1-12 +/-300%
T3 1 0 P1-13 +/-300%
T4 1 1 P1-14 +/-300%
The status of TCM0 ~ TCM1: 0 means DI OFF and 1 means DI ON.
When TCM0 = TCM1 = 0, if it is in Tz mode, then the command is 0. Thus,
if there is no need to use analog voltage as torque command, Tz mode is
applicable and can avoid the problem of zero drift. If it is in T mode, the
command will be the voltage deviation between T-REF and GND. Its input
voltage range is -10V ~ +10V, which mean the corresponding torque is
adjustable (P1-41).
When neither TCM0 nor TCM1 is 0, parameters become the source of torque
command. The command will be executed after TCM0 ~ TCM1 are changed.
There is no need to use CTRG for triggering.
The torque command can be used in torque mode (T or Tz) and speed mode (S or Sz).
When it is in speed mode, it can be regarded as the command input of torque limit.
