2.6 EMI Filter Selection
Item Power Servo Drive Model
Recommended EMI Filter
FootPrint
1PH 3PH
1 100W ASD-B2-0121-B RF007S21AA RF022M43AA N
2 200W ASD-B2-0221-B RF007S21AA RF022M43AA N
3 400W ASD-B2-0421-B RF007S21AA RF022M43AA N
4 750W ASD-B2-0721-B RF007S21AA RF022M43AA N
5 1000W ASD-B2-1021-B RF015B21AA RF075M43BA N
6 1500W ASD-B2-1521-B RF015B21AA RF075M43BA N
7 2000W ASD-B2-2023-B - RF037B43BA N
8 3000W ASD-B2-3023-B - RF037B43BA N
EMI Filter Installation
All electronic equipment (including servo drive) generates high or low frequency noise
during operation and interfere the peripheral equipments via conduction or radiation. With
EMI Filter and the correct installation, much interference can be eliminated. It is suggested
to use Delta’s EMI Filter to suppress the interference better.
When installing servo drive and EMI Filter, please follow the instructions of the user
manual and make sure it meets the following specification.
1. EN61000-6-4 (2001)
2. EN61800-3 (2004) PDS of category C2
3. EN55011+A2 (2007) Class A Group 1
General Precaution
In order to ensure the best performance of EMI Filter, apart from the instructions of servo
drive installation and wiring, please follow the precautions mention below:
1. The servo drive and EMI Filter should be installed on the same metal plate.
2. When installing servo drive and EMI Filter, the servo drive should be installed above
the EMI Filter.
3. The wiring should be as short as possible.
4. The metal plate should be well grounded.
5. The metal cover of the servo drive and EMI Filter or grounding should be firmly fixed
on the metal plate. Also, the contact area should be as large as possible.
6. The suggested installation specification is a servo drive with an EMI filter.
