Delta ASDA-B2 Series User Manual

Chapter 7 Parameters ASDA-B2
7-2 Revision May, 2018
7.2 Lists of Parameters
Monitor and General Output Parameter
Parameter Abbr. Funciton Default Unit
Control Mode
Related
Section
PT S T
P0-00★
VER
Firmware Version
Factory
Setting
N/A O O O -
P0-01■ ALE
Alarm Code Display of Drive
(Seven-segment Display)
N/A N/A O O O
11.1
11.2
11.3
P0-02 STS
Drive Status
00 N/A O O O 7.2
P0-03 MON
Analog Output Monitor
01 N/A O O O -
P0-08★
TSON
Servo On Time
0 Hour -
P0-09★
CM1
Status Monitor Register 1
N/A N/A O O O 4.3.5
P0-10★
CM2
Status Monitor Register 2
N/A N/A O O O 4.3.5
P0-11★
CM3
Status Monitor Register 3
N/A N/A O O O 4.3.5
P0-12★
CM4
Status Monitor Register 4
N/A N/A O O O 4.3.5
P0-13★
CM5
Status Monitor Register 5
N/A N/A O O O 4.3.5
P0-17 CM1A
Status Monitor Register 1
Selection
0 N/A -
P0-18 CM2A
Status Monitor Register 2
Selection
0 N/A -
P0-19 CM3A
Status Monitor Register 3
Selection
0 N/A -
P0-20 CM4A
Status Monitor Register 4
Selection
0 N/A -
P0-21 CM5A
Status Monitor Register 5
Selection
0 N/A -
P0-46★
SVSTS
Servo Digital Output Status
Display
0 N/A O O O -
P1-04 MON1
MON1 Analog Monitor Output
Proportion
100
% (full
scale)
O O O 6.4.4
P1-05 MON2
MON2 Analog Monitor Output
Proportion
100
% (full
scale)
O O O 6.4.4
(★) Read-only register, e.g. parameter P0-00, P0-10 and P4-00, etc.
(▲)
Setting is invalid when Servo On, e.g. parameter P1-00, P1-46 and P2-33, etc.
()
Not effective until re-power on or off the servo drive, e.g. parameter P1-01 and
P3-00.
()
Volatile parameters, e.g. parameter P2-30 and P3-06.
