F.1 ES2 and EX2 Series - General Specifications
This specification is applicable to DVP-ES2/EX2 PLC CPU and their compatible extension
modules.
Item
Specifications
Operating temperature
0 to 55°C
Storage temperature
-25 to 70°C
Operating humidity
5–9
5%
No condensation
Storage humidity
5–95%
No condensation
Work environment No corrosive gas exists.
Installation location
In a control box
Pollution degree
2
Ingress protection
(IP ratings)
IP20
Surge voltage withstand
level
1,500 VAC (Primary-secondary), 1,500 VAC (Primary-PE),
500 VAC (Secondary-PE)
Insulation voltage
Above 5MΩ
The voltage between all inputs/outputs and the ground is 500 VDC.
Noise Immunity
ESD: IEC 61000-4-2 8KV Air Discharge, 4KV Contact Discharge
EFT: IEC 61000-4-4 Power Line: 2KV, Digital I/O: 1KV, Analog &
Communication I/O: 1KV
RS: IEC 61000-4-3 80MHz ~ 1GHz, 10V/m
Surge(IEC 61131-2, IEC 61000-4-5) :
AC power: CM ±2 kV, DM ±1 kV
DC power: CM ±0.5 kV, DM ±0.5 kV
Analog I/O, RS-232(shielded): CM ±1 kV
Digital I/O, RS-485 (unshielded): CM ±1 kV
Ground
The diameter of the ground should not be less than the diameters of
the cables connected to the terminals L and N.
It is required to use grounding if more than one PLC is being used
at the same time.
Vibration / Shock
resistance
Vibration: IEC 60068-2-6(test Fc), 1g DIN rail mount
Shock resistance: IEC 60068-2-27(test Ea), 15 g, 11 ms pulse, 6
shocks in each of 3 axes
Ambient air
temperature-barometric
pressure-altitude
Operating: 1013 ~
795hPa (0 ~ 2000 m)
Storage:1013 ~ 700hPa (0 ~ 3000m)
UL 94 Flame
Classifications
UL 94 V-0
