Delta DVP-EX2 User Manual

DVP-ES2/EX2/EC5/SS2/SA2/SX2/SE&TP Operation Manual
F-4
F.3 EC5 Series - General Specifications
This specification is applicable to DVP-EC5 Series PLC CPU and its compatible extension
modules.
Item
Specifications
Operating temperature
0 to 55°C
Storage temperature
-25 to 70°C
Operating humidity
5–9
5%
No condensation
Storage humidity
5–95%
No condensation
Work environment No corrosive gas exists.
Installation location
In a control box
Pollution degree
2
Ingress protection
(IP ratings)
IP20
Surge voltage withstand
level
2,300 VAC (Primary-secondary), 1,350 VAC (Primary-PE),
500 VAC (Secondary-PE)
Insulation voltage
Above 5MΩ
The voltage between all inputs/outputs and the ground is 500 VDC.
Noise Immunity
ESD: IEC 61000-4-2 8KV Air Discharge, 6KV Contact Discharge
EFT: IEC 61000-4-4 Power Line: 4KV, Digital I/O: 2KV, Analog &
Communication I/O: 2KV
RS: IEC 61000-4-3 26MHz ~ 1GHz, 10V/m
Surge (IEC 61131-2, IEC 61000-4-5):
AC power: CM ±2 kV, DM ±1 kV,
RS-232(shielded): CM ±1 kV
digital I/O, RS-485 (unshielded): CM ±1 kV
Ground
The diameter of the ground should not be less than the diameters of
the cables connected to the terminals L and N.
It is required to use grounding if more than one PLC is being used
at the same time.
Vibration / Shock
resistance
Vibration: IEC 60068-2-6(test Fc), 1g DIN rail mount
Shock resistance: IEC 60068-2-27(test Ea), 15 g, 11 ms pulse, 6
shocks in each of 3 axes
Ambient air
temperature-barometric
pressure-altitude
Operating: 1013 ~ 795hPa (0 ~ 2000 m)
Storage:1013 ~ 700hPa (0 ~ 3000m)
UL 94 Flame
Classifications
UL 94 V-
0
