B-1

Appendix

Setting and Using an Ethernet PLC/Module

Contents

B.1 Specifications for an Ethernet PLC/Module .............................................................. B-2

B.2 Ethernet Control Registers ......................................................................................... B-3

B.2.1 Station Addresses of Ethernet Modules ................................................................ B-3

B.2.2 DVP-SE Series PLC (Ethernet PLC) .................................................................... B-3

B.2.3 DVPEN01-SL (Left-side Ethernet Communication Module) ................................. B-4

B.2.4 DVP-FEN01 (DVP-EH3 Series Ethernet Communication Card) .......................... B-6

B.3 Searching for an Ethernet PLC ................................................................................... B-8

B.3.1 Communication setting .......................................................................................... B-8

B.3.2 Broadcast Search .................................................................................................. B-9

B.3.3 Searching for a Model Specified ......................................................................... B-10

B.3.4 Searching by an IP Address ................................................................................ B-11

B.4 Data Exchange ........................................................................................................... B-13

B.5 EtherNet/IP List .......................................................................................................... B-14

B.5.1 EtherNet/IP Information Supported by DVP-SE series PLCs ............................. B-14

B.5.2 EtherNet/IP Objects Supported by DVP-SE series PLCs ................................... B-15

B.6 RTU Mapping .............................................................................................................. B-21

B.6.1 Setting the RTU Mapping .................................................................................... B-21

B.6.2 Application of the RTU Mapping ......................................................................... B-22
