8
VFD-B Series
DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED
8-3
Group 1 Basic Parameters
Parameters Explanation Settings
Factory
Setting
01-00
Maximum Output Freq. (Fmax)
50.00 to 400.00 Hz 60.00
01-01
Maximum Voltage Frequency
(Fbase)
0.10 to 400.00 Hz 60.00
230V series: 0.1V to 255.0V 220.0
01-02
Maximum Output Voltage
(Vmax)
460V series: 0.1V to 510.0V 440.0
01-03 Mid-Point Frequency (Fmid) 0.10 to 400.00 Hz 0.50
230V: 0.1V to 255V 1.7
01-04 Mid-Point Voltage (Vmid)
460V: 0.1V to 510V 3.4
01-05
Minimum Output Frequency
(Fmin)
0.10 to 400.00 Hz 0.50
230V series: 0.1V to 255.0V 1.7
01-06
Minimum Output Voltage
(Vmin)
460V series: 0.1V to 510.0V 3.4
01-07 Upper bound of freq. 1 to 120% 100
01-08 Lower bound of freq. 00 to100 % 00
01-09 Accel Time 1 0.01 to 3600.0 sec 10.0
01-10 Decel Time 1 0.01 to 3600.0 sec 10.0
01-11 Accel Time 2 0.01 to 3600.0 sec 10.0
01-12 Decel Time 2 0.01 to 3600.0 sec 10.0
01-13 Jog Acceleration Time 0.01 to 3600.0 sec 1.0
01-14 Jog Frequency 0.10 Hz to 400.00 Hz 6.00
00: Linear Accel/Decel
01: Auto Accel, Linear Decel
02: Linear Accel, Auto Decel
03: Auto Accel/Decel
01-15
Auto acceleration /
deceleration (refer to
Accel/Decel Time setting)
04: Auto Accel/Decel (Please refer
to P01-09~12 and P01-18~21)
00
01-16 S-Curve in Accel 00 to 07 00
01-17 S-Curve in Decel 00 to 07 00
01-18 Accel Time 3 0.01 to 3600.0 sec 10.0
01-19 Decel Time 3 0.01 to 3600.0 sec 10.0
01-20 Accel Time 4 0.01 to 3600.0 sec 10.0
01-21 Decel Time 4 0.01 to 3600.0 sec 10.0
01-22 Jog Deceleration Time 0.01 to 3600.0 sec 1.0
01-23 Unit for Accel/Decel Time
00: Unit: 1 sec
01: Unit: 0.1 sec
02: Unit: 0.01 sec
01
