Group 6 Protection Parameters
Parameters
Explanation Settings
Factory
Setting
330V ~ 410V*
06-00
Over-Voltage Stall
Prevention
0: Disable
390*
06-01
Over-Current Stall
Prevention during Accel
20 to 250% 170
06-02
Over-Current Stall
Prevention during
Operation
20 to 250% 170
00: Disabled
01: Enabled during constant speed operation
and continues until OL1 or OL is reached.
02: Enabled during Constant Speed Operation
and halted after Detection
03: Enabled during Accel and continues until
OL1 or OL is reached
06-03
Over-Torque Detection
Mode
04: Enabled during Accel and halted after
Over-Torque Detection
00
06-04
Over-Torque Detection
Level
10 to 200% 150
06-05
Over-Torque Detection
Time
0.1 to 60.0 Sec 0.1
00: Standard Motor
01: Special Motor
06-06
Electronic Thermal
Overload Relay
Selection
02: Disabled
02
06-07
Electronic Thermal
Characteristic
30 to 600 Sec 60
00: No Fault occurred
01: Over Current (oc)
02: Over Voltage (ov)
03: Over Heat (oH)
06-08 Present Fault Record
04: Over Load (oL)
05: Over Load (oL1)
06: External Fault (EF)
07: IGBT Protection (occ)
08: CPU failure (cF3)
06-09 Second Most Recent
Fault Record
09: Hardware Protection Failure (HPF)
10: Current exceed during Acceleration (ocA)
11: Current exceed during Deceleration (ocd)
12: Current exceed during Steady State (ocn)
13: Ground Fault (GFF)
14: Lv
06-10
Third Most Recent
Fault Record
15: CF1
00
