Delta VFD185B43A User Manual

VFD-B Series
DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED
B-2
Fuse Specification Chart
Smaller fuses than those shown in the table are permitted.
Line Fuse
Model
I (A)
(Input)
I (A)
(Output)
I (A) Bussmann P/N
VFD007B21A 11.9 5.0 30 JJN-30
VFD007B23A 5.7 5.0 20 JJN-20
VFD007B43A 3.2 2.7 10 JJS-10
VFD015B21A/B 15.3 7.0 40 JJN-40
VFD015B23A/B 7.6 7.0 25 JJN-25
VFD015B43A 4.3 4.2 15 JJS-15
VFD022B21A 22.0 11 60 JJN-60
VFD022B23A 15.5 11 40 JJN-40
VFD022B43B 5.9 5.5 20 JJS-20
VFD037B23A 20.6 17 60 JJN-60
VFD037B43A 11.2 8.5 30 JJS-30
VFD055B23A 26 25 100 JJN-100
VFD055B43A 14 13 50 JJS-50
VFD075B23A 34 33 125 JJN-125
VFD075B43A 19 18 70 JJS-70
VFD110B23A 50 49 175 JJN-175
VFD110B43A 25 24 90 JJS-90
VFD150B23A 60 65 250 JJN-250
VFD150B43A 32 32 125 JJS-125
VFD185B23A 75 75 300 JJN-300
VFD185B43A 39 38 150 JJS-150
VFD220B23A 90 90 350 JJN-350
VFD220B43A 49 45 175 JJS-175
VFD300B23A 110 120 450 JJN-450
VFD300B43A 60 60 225 JJS-225
VFD370B23A 142 145 500 JJN-500
VFD370B43A 63 73 250 JJS-250
VFD450B43A 90 91 350 JJS-350
VFD550B43A 130 110 400 JJS-400
VFD750B43A 160 150 600 JJS-600
