8
VFD-B Series
DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED
8-11
Group 5 Multi-Step Speed and PLC Parameters
Parameters Explanation Settings
Factory
Setting
05-00 1
st
Step Speed Freq. îš• 0.00 to 400.00 Hz 0.00
05-01 2
nd
Step Speed Freq. îš• 0.00 to 400.00 Hz 0.00
05-02 3
rd
Step Speed Freq. îš• 0.00 to 400.00 Hz 0.00
05-03 4
th
Step Speed Freq. îš• 0.00 to 400.00 Hz 0.00
05-04 5
th
Step Speed Freq. îš• 0.00 to 400.00 Hz 0.00
05-05 6
th
Step Speed Freq. îš• 0.00 to 400.00 Hz 0.00
05-06 7
th
Step Speed Freq. îš• 0.00 to 400.00 Hz 0.00
05-07 8
th
Step Speed Freq. îš• 0.00 to 400.00 Hz 0.00
05-08 9
th
Step Speed Freq. îš• 0.00 to 400.00 Hz 0.00
05-09 10
th
Step Speed Freq. îš• 0.00 to 400.00 Hz 0.00
05-10 11
th
Step Speed Freq. îš• 0.00 to 400.00 Hz 0.00
05-11 12
th
Step Speed Freq. îš• 0.00 to 400.00 Hz 0.00
05-12 13
th
Step Speed Freq. îš• 0.00 to 400.00 Hz 0.00
05-13 14
th
Step Speed Freq. îš• 0.00 to 400.00 Hz 0.00
05-14 15
th
Step Speed Freq. îš• 0.00 to 400.00 Hz 0.00
00: Disable PLC Operation
01: Execute one program cycle
02: Continuously execute program
cycles
05-15 PLC Mode
03: Execute one program cycle step by
step
04: Continuously execute program
cycles step by step
00
05-16 PLC Forward/ Reverse
Motion
00 to 32767 (00: FWD 01: REV) 00
05-17 Time Duration Step 1 0.0 to 65500 sec 0.0
05-18 Time Duration Step 2 0.0 to 65500 sec 0.0
05-19 Time Duration Step 3 0.0 to 65500 sec 0.0
05-20 Time Duration Step 4 0.0 to 65500 sec 0.0
05-21 Time Duration Step 5 0.0 to 65500 sec 0.0
05-22 Time Duration Step 6 0.0 to 65500 sec 0.0
05-23 Time Duration Step 7 0.0 to 65500 sec 0.0
05-24 Time Duration Step 8 0.0 to 65500 Sec 0.0
05-25 Time Duration Step 9 0.0 to 65500 Sec 0.0
05-26 Time Duration Step 10 0.0 to 65500 Sec 0.0
05-27 Time Duration Step 11 0.0 to 65500 Sec 0.0
05-28 Time Duration Step 12 0.0 to 65500 Sec 0.0
05-29 Time Duration Step 13 0.0 to 65500 Sec 0.0
05-30 Time Duration Step 14 0.0 to 65500 Sec 0.0
05-31 Time Duration Step 15 0.0 to 65500 Sec 0.0
