Chapter 9 Specification C2000-HS
9-2
9-1 460V Series
Frame Size D0 D E F G H
Model VFD-_ _ _ C43x-HS
300 370 750 1100 1600 2200 3550
Output Rating
Normal Load
Rated Output Capacity [kVA] 48 58 120 175 247 367 544
Rated Output Current [A] 60 73 150 220 310 460 683
Applicable Motor Output [kW] 30 37 75 110 160 220 355
Applicable Motor Output [HP] 40 50 100 150 215 300 475
Overload Capacity
120% of rated output current: 1 minute for every 5 minutes;
160% of rated output current: 3 seconds for every 30 seconds
Max. Output Frequency [Hz] 1500Hz 1200Hz 1000Hz 900Hz
Carrier Frequency [kHz]
2–15
(Default: 10)
2–15
(Default: 8)
2–12
(Default: 8)
2–10
(Default: 6)
2–9
(Default:6)
Input Rating
Input Current [A] 63 74 157 207 300 400 625
Rated Voltage／Frequency
3-phase AC 380V–480V (-15% +10%), 50 / 60Hz
Operating Voltage Range
323–528V
AC
Frequency Tolerance
47–63Hz
Efficiency [%] 97.50 97.78 97.50 97.68 97.09 98.39
Power Factor >0.98
Drive Weight [Kg] 38 Kg 40 Kg 66 Kg 88 Kg 138 Kg 228 Kg
Cooling Method Fan cooling
Braking Chopper Frame D0–H: Optional
DC choke Frame D0–H: Built-in, EN61000-3-12
EMC Filter Frame D0–H: Optional
Table 9-1
NOTE
1. The carrier frequency is default. Increasing the carrier frequency requires a reduction in current. Refer to Section 9-4 for
Derating Protection drawing.
2. The C2000-HS does not support the PG and IM/ PM Sensorless mode.
3. Select the AC motor drive with capacity one grade larger for the impact load application.
4. The rated input current will be affected not only by Power Transformer and the connection of the reactors on input side, but
also fluctuates with the impedance of power side.
5. For Frame D0 and above, if the last character of the model is A then it is under IP20 protection level, but the wiring terminal is
under IP00 protection level.
