Chapter 12 Description of Parameter SettingsC2000-HS
12.1-00-1
Chapter 12 Description of Parameter Settings
12-1 Description of Parameter Settings
00 Drive Parameters
This parameter can be set during operation.
Identity Code of the AC Motor Drive
Default: Read only
Settings Read Only
Display AC Motor Drive Rated Current
Default: Read only
Settings Read Only
Pr. 00-00 displays the identity code of the AC motor drive. Use the following specification table
to check if Pr. 00-01 setting is the rated current of the AC motor drive. Pr. 00-01 corresponds to
the identity code Pr.00-00.
Frame D0 D E F G H
kW 30 37 75 110 160 220 355
HP 40 50 100 150 215 300 475
Identity Code 25 27 33 37 41 45 51
Rated Current 60 73 150 220 310 460 683
Parameter Reset
Default: 0
Settings 0: No Function
1: Write protection for parameters
5: Reset kWh display to 0
6: Reset PLC (including CANopen Master Index)
7: Reset CANopen Index (Slave)
10: Reset all parameters to defaults
When set to 1: all parameters are read only except Pr. 00-02, Pr. 00-07, and Pr. 00-08. Set Pr.
00-02 to 0 before changing other parameter settings.
When set to 10: all parameters are reset to defaults. If password is set in Pr. 00-08, input the
password in Pr. 00-07 to reset to defaults.
When set to 5: kWh displayed value can be reset to 0 even when the drive is operating. Pr.
05-26, Pr. 05-27, Pr. 05-28, Pr. 05-29 and Pr. 05-30 are reset to 0.
When set to 6: clear internal PLC program (includes the related settings of PLC internal
CANopen master)
When set to 7: reset the related settings of CANopen slave.
When set to 6, 7, 10: reboot the motor drive after setting.
