Chapter 7 Optional AccessoriesC2000-HS
7-15
7-5 EMC Filter
Following table is the external EMC filter for C2000 series, user can choose corresponding zero
phase reactor and suitable shielded cable length in accord to required noise emission and
electromagnetic interference level to have the best configuration to suppress the electromagnetic
interference. When the application does not consider RE and only needs CE to comply with C2 or C1,
there is no need to install zero phase reactor in input side.
C2000-HS
Filter model name
Carrier
frequency
Conducted Emission
Radiation
Emission
Frame Model
Rated input current
[A]
Output shielded
cable length
EN61800-3
EN618000-3 C2
D0
VFD300C43S-HS 63 B84143A0120R105 ≤10kHz 100m C3
VFD370C43S-HS 74 B84143A0120R105 ≤10kHz 100m C3
D VFD750C43A-HS 157 B84143B0180S080 ≤10kHz 100m C3
E VFD1100C43A-HS 207 B84143B0250S080 ≤8kHz 100m C3
F VFD1600C43A-HS 300 B84143B0400S080 ≤8kHz 100m C3
G VFD2200C43A-HS 400 B84143B0600S080 ≤6kHz 100m C3
H VFD3550C43A-HS 625 B84143B1000S080 ≤6kHz 100m C3
EMC Filter Installation
All electrical equipment, including AC motor drives, will generate high frequency/ low frequency noise
and will interfere with peripheral equipment by radiation or conduction when in operation. By using an EMC
filter with correct installation, much interference can be eliminated. It is recommended to use DELTA EMC
filter to have the best interference elimination performance.
We assure that it can comply with following rules when AC motor drive and EMC filter are installed and
wired according to user manual:
1. EN61000-6-4
2. EN61800-3: 1996
3. EN55011 (1991) Class A Group 1
General precaution
To ensure EMC filter can maximize the effect of suppressing the interference of AC motor drive, the
installation and wiring of AC motor drive should follow the user manual. In addition, be sure to observe the
following precautions:
1. EMC filter and AC motor drive should be installed on the same metal plate.
2. Please install AC motor drive on footprint EMC filter or install EMC filter as close as possible to the AC
motor drive.
3. Please wire as short as possible.
Table 7-11
