Denon AVR-X3200W Service Manual

SCHEMATIC DIAGRAMS (10/33)
SCH10_ZONE DAC
ANALOG AUDIO DIGITAL AUDIO TMDS SIGNAL ANALOG VIDEO GND LINE POWER- LINE POWER+ LINE DIGITAL VIDEO STBY POWER
TO AUDIO PLD
TO DIGITAL CONNECT
ZONE2 DAC
Z2L
Z2R
CPVDD
CAPP
CPGND
CAPM
VNEG
OUTL
OUTR
AVDD
AGND
DEMP
DVDD
DGND
LDOO
XSMT
FMT
LRCK
DIN
BCK
SCK
FLT
CPVDD
CAPP
CPGND
CAPM
VNEG
OUTL
OUTR
AVDD
AGND
DEMP
DVDD
DGND
LDOO
XSMT
FMT
LRCK
DIN
BCK
SCK
FLT
Z3L
Z3R
ZONE3 DAC
(PAGE 7_A2,A3)
(PAGE 1_A6)
OPEN
C3219
OPEN
C3220
0.1
C3223
10/6.3V
C3221
10/6.3V
C3222
0.1
C3224
0.1
C3225
22/16V
C3204
0.1
C3201
0.1
C3202
0.1
C3203
2.2/6.3V
C3205
2.2/6.3V
R3203
470
R3204
470
C3208
2200P
C3209
2200P
C3206
0.1
C3207
10/6.3V
12345678910
11 12 15 16 17 18 19 201413
IC321
PCM5100PW
R
R3202
10K
C3213
0.1
C3210
0.1
C3211
0.1
C3212
2.2/6.3V
C3214
2.2/6.3V
R3208
470
R3209
470
C3217
2200P
C3218
2200P
C3215
0.1
C3216
10/6.3V
12345678910
11 12 15 16 17 18 19 201413
IC322
PCM5100PWR
R3207
10K
R3201
10K
R3206
10K
R3205
10K
R3210
10K
3
NC
GND
STBY
VOUTVIN
2
4
51
IC323
BU33TD3WG
R3211
10K
ZONE_DA C
A+5V
DGND
Z3DACM CK Z3DACL RCK Z3DACDA TA
Z3DACB CK Z2DACM CK
Z2DACL RCK Z2DACDA TA
Z2DACB CK
DEMZ3 DEMZ2
DAZONE2L
DAZONE2R
DAZONE3L
DAZONE3R
DAGND
Z3DACM UTE
Z2DACM UTE
Z2DACM UTE
Z3DACM UTE
DEMZ2 DEMZ3 Z2DACB CK
Z2DACDA TA
Z2DACL RCK Z2DACM CK
Z3DACB
CK
Z3DACDA TA
Z3DACL RCK Z3DACM CK
Z3DACM UTE
Z3DACL RCK
Z3DACDA TA
Z3DACB CK
Z3DACM CK
DEMZ3
Z2DACM UTE
Z2DACL RCK
Z2DACDA TA
Z2DACB CK
Z2DACM CK
DEMZ2
4A
TO A4
5F
TO F5
135
1
2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
A
B
C
D
E
F
G
H
J
K
L
M
A
B
C
D
E
F
G
H
J
K
L
M
1
2 3 4 5 6 7 8 9 10 11 12 13 14 15 16

Denon AVR-X3200W Specifications

General

Receiver type	Surround
Input sensitivity	200 mV
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	180 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	8
Audio (L/R) in	5
Composite video in	3
USB ports quantity	1
Component video (YPbPr/YCbCr) in	2
12V trigger	Yes
Speakers connectivity type	-
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	vTuner
Optical drive included	No
Display	LCD
Product color	Black
Audio decoders	DTS-HD Master Audio, Dolby Surround, Dolby TrueHD
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	650 W

Weight and Dimensions

Depth	388 mm
Width	434 mm
Height	167 mm
Weight	11300 g
