Denon AVR-X3200W Service Manual

2. PANEL / REMOTE LOCK Selection Mode
2.1. Actions
Switch the PANEL LOCK and REMOTE LOCK modes between on and off.
2.2. Starting up
While holding down buttons "
TUNER PRESET CH+
" and "
ZONE2 SOURCE
" simultaneously, press the power button to
turn on the power.
Select the desired mode using the "
TUNER PRESET CH+
" button, then press the "
STATUS
" button to conrm.
2.3. Displaying and Selecting Each Mode
The information shown on the display switches each time the "
TUNER PRESET CH+
" button is pressed.
Press the "
STATUS
" button to set the currently displayed mode and restart the device.
The setting with "
*
" is selected for each mode.
q
FLD
F P / V O L L O C K * O N
The buttons on the unit and the master volume knob does not function.
w
FLD
F P L O C K O N
The buttons on the unit does not function.
e
FLD
F P L O C K O F F
The PANEL LOCK mode is turned off.
r
FLD
R C L O C K O n
The device cannot be operated by the remote control.
t
FLD
R C L O C K * O F F
The REMOTE LOCK mode is turned off.
