Denon AVR-X3200W Service Manual

1. Version Display Mode
1.1. Actions
Version information is displayed when the device is started in this mode.
1.2. Starting up
While holding down buttons "DIMMER" and "STATUS" simultaneously, press the power button to turn on the power.
then press the "STATUS" button to display the information in section 1.3 on the display.
b
The version list is also displayed on GUI while the version is displayed on the display.
1.3. Display Order
Error information(See "1.4. Error display") →
q
Model destination information →
w
Serial Number
→
e
Firmware Package Version →
r
Main µ-com →
t
Main 1st Boot Loader →
y
DSP ROM
→
u
Audio PLD →
i
Video PLD →
o
GUI SFLASH →
Q0
Ethernet 1st Boot Loader, Hardware ID
→
Q1
Ethernet 2nd Boot Loader, Rhapsody Flag →
Q2
Ethernet IMAGE →
Q3
Ethernet MAC ADDRESS information
→
Q4
BT MAC Address information
q
Model destination information :
FLD
A V R - X 3 2 0 0 W E 3 *
FLD
A V R - X 3 2 0 0 W E 2 *
FLD
A V R - X 3 2 0 0 W E 1 C *
w
Serial Number：
FLD
S / N . * * * * * * * * * *
e
Firmware Package Version：
FLD
P a c k a g e : * * * *
r
Main µ-com Version information :
FLD
M a i n : * * * * # # # # *
*
： Main version,
#
： Sub version
t
Main 1st Boot Loader :
FLD
M a i n F B L : * * . * *
y
DSP ROM :
FLD
D S P : * * . * *
u
Audio PLD :
FLD
A u d i o P L D : * * . * *
i
Video PLD
FLD
V i d e o P L D : * * . * *
o
GUI SFLASH :
FLD
G U I : @ @ $ \ * * * *
@
： Model code,
$
： Brand code,
\
： Region code,
*
： version
19

Denon AVR-X3200W Specifications

General

Receiver type	Surround
Input sensitivity	200 mV
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	180 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	8
Audio (L/R) in	5
Composite video in	3
USB ports quantity	1
Component video (YPbPr/YCbCr) in	2
12V trigger	Yes
Speakers connectivity type	-
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	vTuner
Optical drive included	No
Display	LCD
Product color	Black
Audio decoders	DTS-HD Master Audio, Dolby Surround, Dolby TrueHD
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	650 W

Weight and Dimensions

Depth	388 mm
Width	434 mm
Height	167 mm
Weight	11300 g
