Denon RCD-M38 Service Manual

89
INPUT PCB ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC11 90M-HC108700R IC NJW1153FG1 HVINJW1153FG1
IC12 00D9430007108 IC NJM2068MD-TE1 HVINJM2068MDTE1
IC13 00D9430005702 IC KA79L08AZT HVIKA79L08AZT
IC14 00D9430005605 IC KA78L08AZT HVIKA78L08AZT
IC15 00D2623552904 IC AK4385ET CVIAK4385ET
IC17 00D9430007108 IC NJM2068MDTE1 HVINJM2068MDTE1
IC18 00D9430038902 IC LM1117S-3.3V EK HVILM1117S-3V3
IC19 90M-HC900170R IC KIA1117S00 EK CVIKIA1117S00
IC41 00D9430007108 IC NJM2068MDTE1 HVINJM2068MDTE1
IC91 00D2631100021 IC KIA7812API-U/P HVIKIA7812API
IC93 90M-HC300780R IC KIA7808API HVIKIA7808API
D101,102 90M-HD201800R DIODE 1SS355T HVD1SS355T
D103 90M-HD201800R DIODE 1SS355T E2 HVD1SS355T
D106-112 90M-HD201800R DIODE 1SS355T HVD1SS355T
D113,114 90M-HD201820R DIODE SCHOTTKEY RB160L60TE25 HVDRB160L60TE25
D909 90M-HD201840R DIODE 1SR159 HVD1SR159-200
D913 90M-HD201840R DIODE 1SR159 HVD1SR159-200
D945,946 90M-HD201840R DIODE 1SR159 HVD1SR159-200
Q103,104 90M-HT300970R CHIP TR KTC2875B HVTKTC2875B
Q106 90M-BA001600R CHIP TR KRA107S HVTKRA107S
Q108 00D9430037903 CHIP TR KRC102S HVTKRC102S
Q112 00D9430037903 CHIP TR KRC102S HVTKRC102S
CAPACITORS GROUP
C101-108 nsp CHIP CAP 180pF 50V CCUS1H181JA
C109,110 nsp ELECT CAP 10uF 50V CCEA1HH100T
C111-114 nsp CHIP CAP 0.1uF 50V CCUS1H104KC
C115-118 nsp ELECT CAP 10uF 50V CCEA1HH100T
C119-121 nsp CHIP CAP 0.1uF 50V CCUS1H104KC
C122-125 nsp ELECT CAP 10uF 50V CCEA1HH100T
C126-128 nsp CHIP CAP 180pF 50V CCUS1H181JA
C129 nsp ELECT CAP 1uF 100V CCEA2ARFO1R0T
C130 nsp ELECT CAP 4.7uF 50V CCEA1HH4R7T
C131 943139001210S METALLIZED FLIM CAP 0.22UF 100V CCME2A224JXT
C132,133 nsp CAP MYLAR 4700PF 50V HCQI1H472JZT
C134 943139001210S METALLIZED FLIM CAP 0.22UF 100V CCME2A224JXT
C135 nsp ELECT CAP 4.7uF 50V CCEA1HH4R7T
C140,141 nsp CHIP CAP 0.01uF 50V CCUS1H103KC
C142-144 nsp ELECT CAP 47UF 50V CCEA1HRFO470T
C145 nsp ELECT CAP 100uF 50V CCEA1HRFO101T
C146,147 nsp CHIP CAP 0.1uF 50V CCUS1H104KC
C148,149 nsp ELECT CAP 22UF 50V CCEA1HRFO220T
C150 nsp CHIP CAP 0.01uF 50V CCUS1H103KC
C151,152 nsp CERAMIC CAP 39pF 50V CCCT1H390JC
C153 nsp CHIP CAP 0.01uF 50V CCUS1H103KC
C154,155 nsp ELECT CAP 22UF 50V CCEA1HRFO220T
C156 nsp ELECT CAP 10uF 63V CCEA1JRFO100T
