Denon RCD-M38 Service Manual

91
MAIN PCB ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC71 943239001350S IC HYBRID CVISTK4142MK2
IC92 00D9430089702 IC NJM7912FA HVINJM7912FA
IC94 90M-HC300790R IC KIA78R05PI HVIKIA78R05PI
IC96 00D2622944946 IC BA33BC0FP BVIBA33BC0FP
D702 00D9430209400 DIODE 1N4003SRT CVD1N4003SRT
D703,704 00D9430087102 ZENER DIODE MTZJ20B 1/2W HVDMTZJ20BT
D705 00D9430209400 DIODE 1N4003SRT CVD1N4003SRT
D706-709 90M-HD201290R DIODE 1SS133MT HVD1SS133MT
D710,711 00D9430041902 SCHOTTKY DIODE 1N5819 HVD1N5819T
D712 90M-HE200390R DIODE GBJ1006 HVDGBJ1006
D713,714 90M-HD201290R DIODE 1SS133MT HVD1SS133MT
D801 90M-HI101090R LED SPR39MVW3 2COLOR HVDSPR39MVW3
D802,803 90M-HD201290R DIODE 1SS133MT HVD1SS133MT
D806-812 90M-HD201290R DIODE 1SS133MT HVD1SS133MT
D813-815 90M-HD201800R DIODE 1SS355T HVD1SS355T
D901,902 00D9430110008 DIODE 1N4003ST CVD1N4003ST
D903,904 nsp DIODE SCHOTTKY HVD21DQ10T
D905,906 00D9430110008 DIODE 1N4003ST CVD1N4003ST
D907 00D9430209400 DIODE 1N4003SRT CVD1N4003SRT
D908 00D9430110008 DIODE 1N4003ST CVD1N4003ST
D910,911 00D9430209400 DIODE 1N4003SRT CVD1N4003SRT
D915 00D9430041902 SCHOTTKY DIODE 1N5819 HVD1N5819T
D916,917 00D9430110008 DIODE 1N4003ST CVD1N4003ST
D918,919 00D9430041902 SCHOTTKY DIODE 1N5819 HVD1N5819T
D920 90M-HD201290R DIODE 1SS133MT HVD1SS133MT
D921 nsp COPPER WIRE C3A206
D922-924 90M-HD201290R DIODE 1SS133MT HVD1SS133MT
D925 nsp DIODE ZENER HVDMTZJ12BT
D928-934 90M-HD201290R DIODE 1SS133MT HVD1SS133MT
D937,938 90M-HD201290R DIODE 1SS133MT HVD1SS133MT
D939 nsp COPPER WIRE C3A206
D940 90M-HD201290R DIODE 1SS133MT HVD1SS133MT
D941 90M-HD201290R DIODE 1SS133MT HVD1SS133MT
D942 90M-HD201290R DIODE 1SS133MT E3 HVD1SS133MT
D943 00D9430087500 ZENER DIODE 5.6V 1/2W HVDMTZJ5.6BT
D945 00D9430110008 DIODE 1N4003ST CVD1N4003ST
D946 90M-HD201290R DIODE 1SS133MT HVD1SS133MT
D949 90M-HD201290R DIODE 1SS133MT HVD1SS133MT
D950 00D9430110008 DIODE 1N4003ST CVD1N4003ST
D951 90M-HD201290R DIODE 1SS133MT HVD1SS133MT
Q701,702 90M-HT600040R TR KTA1267YT HVTKTA1267YT
Q703 943219006820S TR KTC1027Y CVTKTC1027YT
Q704 90M-BA001460R TR KRC107M HVTKRC107MT
Q705 90M-BA001450R TR KRA107MT HVTKRA107MT
Q706-708 00D9430154404 TR KTC3198Y HVTKTC3198YT
Q709 90M-BA001460R TR KRC107M HVTKRC107MT
Q710 00D9430154200 TR KRA102M HVTKRA102MT
Q711 90M-BA001460R TR KRC107M HVTKRC107MT
