DeWalt XR DCG409VS Original Instructions

53
ENGLISH
Inserting and Removing the Battery Pack
from the Tool (Fig. B)
NOTE: Make sure your battery pack
13
is fullycharged.
Features
E-Clutch™
This unit is equipped with an E-Clutch™ (Electronic Clutch),
which in the event of a high-load the unit will be shut off to
reduce the reaction torque to the user. The switch needs to be
cycled (turned on and off) to restarttool.
Kickback Brake™
When a pinch, stall, or bind-up event is sensed the electronic
brake engages with maximum force to quickly stop the wheel,
reduce the movement of the grinder, and shut the grinder off.
The switch needs to be cycled (turned on and off) to restart
thetool.
Power-Off™ Overload Protection
The power supply to the motor will be reduced in case of motor
overload. With continued motor overload, the tool will shut
off. The switch needs to be cycled (turned on and off) to restart
tool. The tool will power off each time the current load reaches
the overload current value (motor burn-up point). If continued
overload shutdowns occur, apply less force/weight on the tool
until the tool will function without the overloadengaging.
Electronic Soft Start
This feature limits the initial start up speed, allowing the tool to
build up to full speed gradually over a 1secondperiod.
ASSEMBLY AND ADJUSTMENTS

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect tool from power
source before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can causeinjury.
Intended Use
The DCG409VS and DCG416VS cordless angle grinder have been
designed for professional cutting, grinding, sanding and wire
brushapplications.
DO NOT use under wet conditions or in the presence of
flammable liquids orgases.
This cordless angle grinder is a professional powertool.
DO NOT let children come into contact with the tool. Supervision
is required when inexperienced operators use thistool.
• Young children and the infirm. This appliance is not
intended for use by young children or infirm persons
withoutsupervision.
• This product is not intended for use by persons (including
children) suffering from diminished physical, sensory or
mental abilities; lack of experience, knowledge or skills
unless they are supervised by a person responsible for their
safety. Children should never be left alone with thisproduct.
Description (Fig. A)

WARNING: Never modify the power tool or any part of it.
Damage or personal injury couldresult.
1
Paddle switch
2
Slide switch
3
Lock-off lever
4
Spindle lock button
5
Spindle
6
Side handle
7
Backing flange
8
Locking flange
9
Type A guard 125mm
10
Type B guard 125mm (do not use for cut-off operations)
11
Guard release lever
12
Variable speed dial
13
Battery pack
14
Battery release button
Date Code Position (Fig.F)
The date code
29
, which also includes the year of manufacture,
is printed into thehousing.
Example:
2022XX XX
Year and Week of Manufacture
Markings on Tool
The following pictograms are shown on the tool:
a
Read instruction manual beforeuse.
g
Wear earprotection.
f
Wear eyeprotection
Always operate with twohands.
Do not use the guard for cut-offoperations.
NOTE: Battery packs, chargers and kitboxes are not included
with N models. Battery packs and chargers are not included with
NT models. Bmodels include Bluetooth® batterypacks.
NOTE: The Bluetooth® word mark and logos are registered
trademarks owned by the Bluetooth®, SIG, Inc. and any use of
such marks by DeWALT is under license. Other trademarks and
trade names are those of their respectiveowners.
• Check for damage to the tool, parts or accessories which may
have occurred duringtransport.
• Take the time to thoroughly read and understand this manual
prior tooperation.
