3590EKR, 3590EXP, 3590EXT, CPWE, CPWET series indicator E-AF09_02_16.03_EN_U
3. INSTALLATION
3.1 POWER SUPPLY
- The 3590E indicator is powered with 12Vdc voltage , through an internal adapter which converts the 100 ÷ 240Vac,
50÷60Hz mains voltage and 6 Vdc, from the built-in battery (fitted, depending on the model).
TO POWER the instrument through the 240 Vac mains, or TO RECHARGE the battery, insert the plug and the adapter to the
240 Vac mains socket.
- The CPWE indicator is powered with 12÷24 Vdc voltage.
- The CPWET indicator is powered with 12 ÷ 24Vdc voltage.
To connect it to the power mains, the safety regulations must be observed, including the use of a "clean" line without
disturbances or interference caused by other electronic equipment.
Version with rechargeable battery: the battery inside the indicator, lasts about 25 hours (without the expansion board, with
1-cell platform) and it needs a recharging time of about 12 hours.
BATTERY FEATURES
Material LEAD
Power 4,5 Ah
Voltage 6 V
THE BATTERY MUST BE SUPPLIED DIRECTLY FROM THE MANUFACTURER.
NOTE: it is advisable to completely recharge it (12 hours) in the first installation of the instrument; we RECOMMEND
disconnecting the battery if the instrument is not going to be used for more than 30 days.
Do not connect other equipment to the same socket as the one that the adapter is in.
Do not step on or crush the power supply cable
3.2 START UP
TO TURN ON the 3590E or the CPWET press the C key until the display turns on; then release.
The CPWE instead is automatically turned on as soon as it is powered.
The display shows:
- Initially a welcome message (settable in the TECHNICAL SET-UP, << LoGo >> StEP, TECH.MAN.REF) while the
instrument carries out a series of checking and preheating self tests.
- E-AF09 - XX name of the installed software, in which XX identifies the software language.
XX.YY is the software version installed.
- “EXECUTION AUTOZERO”
The instrument carries out the "autozero at start-up” function: if a weight is detected within the percentile set in the <<
Auto-0 >> step (TECH.MAN.REF.), it is cleared; if the weight is not within this tolerance:
- with a non approved instrument, the display shows the weight after a few instants,
- with an approved instrument, the message “EXECUTION AUTOZERO” appears continuously on the display, until the
weight is within tolerance.
The autozero function at start-up can be disabled in the set-up environment (only with a non approved instrument), see the
<<Auto 0>> parameter.
By pressing the 2ndF key for an instant while the version is shown in the display, the indicator will show in this order:
XX.YY in which XX indicates the instrument type, YY indicates the metrological software version.
XX.YY.ZZ is the installed software version.
HH is the installed hardware version (08).
LEGAL FOR TRADE or HIGH RESOLUTION if the instrument is APPROVED or UNAPPROVED, respectively.
9.XXXXX is the g gravity value (only with APPROVED instrument).
3.3 TURNING OFF THE INSTRUMENT
TO TURN OFF the 3590E/CPWET or TO RESTART the CPWE keep the C key pressed until the “- OFF -“ message appears
on the LED display and “ *** POWER OFF *** ” on the LCD display.
TO TURN OFF the CPWE remove the instrument’s power supply.
