- 145 -
LP Engine G430(3.0L) Base Engine Service Procedure
Distributor Lower Bushing
and Thrust Washer Installation
Tools Required
• J 9535 Distributor Lower Bushing Installer
1. Use the J 9535 in order to drive the thrust washer (if
removed) into the cylinder block.
2. Use the J 9535 with the driver-bolt in the driver
handle.
3. Install the driver into the new bushing from the large
inside diameter.
4. Drive the new bushing into the cylinder block until
the J 9535 bottoms against the cylinder block.
Piston and Connecting Rod
Disassemble
Tools Required
• J 24086-C Piston Pin Removal Set
1. Remove the piston rings from the pistons.
2. Remove the pin from the piston.
NOTICE
After the J 24086-C Installer bottoms on the support
assembly, do not exceed 34,475 kPa (5000 psi) or the
tool may be damaged.
VE064-3L
VE063-3L
VE062-3L
VE061-3L
