- 176 -
LP Engine G430(3.0L) Base Engine Service Procedure
Distributor Installation
IMPORTANT: To ensure correct ignition timing, the
distributor must be installed in the correct position.
Position the engine at top dead center on number one
cylinder. The distributor cap must be removed in order
to position the rotor when installing the distributor.
1. Install the distributor (2) and new gasket (3), making
sure the distributor rotor is pointing to number one
tower on the distributor cap.
2. Install the distributor hold down (5) and bolt (6).
Tighten
Tighten the hold down bolt to 27 N•m (20 lb•ft).
3. Connect the primary ignition harness (4) to the
ignition coil.
4. Connect the secondary ignition wires (1) to the
spark plugs and the ignition coil.
Engine Flywheel Installation
IMPORTANT: Note the position and direction of the
engine flywheel before removal.
The engine flywheel must be reinstalled to the original
position and direction.
1. Install the engine flywheel.
2. Install the engine flywheel bolts.
Tighten
Tighten the flywheel bolts to 88 N•m (65 lb•ft).
NOTE: The hole (2) of flywheel should be aligned with
the pin (1) of crankshaft.
VE009-3L
VE010-3L
