- 78 -
LP Engine G430(3.0L) LP Fuel System
Disassembly & Assembly
LP Gas Carburetor
Remove & Install LP Gas Carburetor
1. Disconnect all lines and linkage (not shown).
2. Remove two nuts (1).
3. Remove carburetor (2) and the gasket (3).
NOTE: For the installation of the LP gas carburetor,
reverse the removal steps.
5. Replace gasket.
6. Torque attaching nuts to specification.
Disassemble LP Gas Carburetor
Start By:
a. Remove LP Gas Carburetor.
1. Remove four screws (1) and cover (2).
2. Remove spring (3). Remove diaphragm assembly
(4).
To Next Page
