Duplo DBM-120 Instruction Manual

44
Stapler folder
Saddle-stapling and folding/Center-folding
Length: 200 to 450 mm (7.87" to 17.72")
Width : 200 to 320 mm (7.87" to 12.60")
A3 : 297 × 420 mm (11.69" × 16.54") LGL : 8.5" × 14" (215.9 × 355.6 mm)
A4 : 210 × 297 mm (8.27" × 11.69") LTR : 8.5" × 11" (215.9 × 279.4 mm)
B4 : 257 × 364 mm (10.12" × 14.33") LGR: 11" × 17" (279.4 × 431.8 mm)
A3SR: 320 × 450 mm (12.60" × 17.72")
Side-stapling (feed direction: wide edge leading)
Length: 139 to 231 mm (5.47" to 9.09")
Width : 200 to 320 mm (7.87" to 12.60")
A4 : 210 × 297 mm (8.27" × 11.69") LTR: 8.5" × 11" (215.9 × 279.4 mm)
A5 : 148 × 210 mm (5.83" × 8.27") IV : 5.5" × 8.5" (139.7 × 215.9 mm)
B5 : 182 × 257 mm (7.17" × 10.12")
Corner-stapling (feed direction: wide edge leading)
A4 : 210 × 297 mm (8.27" × 11.69") LTR: 8.5" × 11" (215.9 × 279.4 mm)
Stencil fine quality paper, medium quality paper, fine quality paper (64 to 128 g/m
2
(17 to
34 lb))
NOTE : The cover must be above 80 g/m
2
(22 lb).
Under both side and corner-stapling mode, in case of 64 g/m
2
(17 lb), up to 10
sheets.
40 sets/minute (A4-80 g/m
2
(22 lb), 10 sheets)
2
Fine quality paper: 80 g/m
2
(22 lb). Equivalent to 25 sheets or less
Fine quality paper: 80 g/m
2
(22 lb). Equivalent to 25 sheets or less
Saddle-stapled/folded paper : About 20 sets for single-folding of 10 sheets of A4 vertical
80 g/m
2
(22 lb) paper (Reference value)
Side-stapled paper: Stacking height of 90 mm (3.54"). About 70 sets of 10 sheets of A4
80 g/m
2
(22 lb) paper (Reference values)
Paper jam (paper receiving section, paper aligning section, stapling section, folding
section, paper ejecting section)
Remaining-staple
Top cover open/close
Automatic paper size setting
74 dB (including the peak)
220 to 240 V AC 50/60 Hz (120 V AC 60 Hz)
1 A (220 to 240 V AC) / 2 A (120 V AC)
DBM-120 : W × D × H = 702 × 550 × 571 mm (27.64" × 21.65" × 22.48")
DBM-120 + Stacker: W × D × H = 1263 × 550 × 594 mm (49.72" × 21.65" × 23.39")
DBM-120 + 120T + Stacker + Cabinet: W × D × H = 1772 × 560 × 739 mm
(69.76" × 22.05" × 29.09")
(The DBM-120T and cabinet are optional products.)
DBM-120: 84 kg (186 lb), Stacker: 7 kg (16 lb)
Type
Paper size
Paper weight
Maximum processing
speed
Stapler
Stapling ability
Folding ability
Paper receivable
amount
Detection function
Additional function
Acoustic noise
Power supply
Current consumption
Dimensions
Mass (Weight)
13. SPECIFICATIONS
Model DBM-120
Specifications and dimensions are subject to change without prior notice for improvements.

Duplo DBM-120 Specifications

General

Brand	Duplo
Model	DBM-120
Category	Folding Machines
Language	English
