Eaton 600 A 15 kV class push-OP Installation And Operation Instruction Manual

Accessories
These accessories are available. Contact your Eaton
representative for additional information.
Low voltage closing
The Low Voltage Closing Accessory utilizes 120 or 240
VAC for closing power (Figures 22, 23, and 24). Multiple
low voltage closing accessories are available for reclosers
equipped with low voltage closing. The low voltage closing
accessories available for the Form 4D recloser control
include the appropriate receptacles and wiring based upon
the input supply voltage. Table 6 lists the available low
voltage closing input/output receptacles and cables for the
Form 4D pole-mount recloser control.
Cabinet ordering accessories

AISI 304 stainless steel cabinet construction.
Incoming power receptacles
The Incoming Power Receptacle allows the user to
conveniently plug the power cable into the control,
eliminating the need for hardwiring to the control. Various
options are available based upon the input power voltage,
and phase sensing requirements. Table 6 includes the
available input receptacles and cables for the Form 4D
pole-mount recloser control.
Internal voltage sensing
A four-wire cable and input receptacle accessory
(Table 7) is required for Type NOVA three-phase reclosers
with the internal voltage sensing (IVS) option. Internal
voltage sensors, located on the source side, indicate voltage
magnitude within an accuracy 2% or better and a phase
degree accuracy within 1.5 degrees (includes sensor, cable,
and control). The 4-pin receptacle accessory is pre-wired to
the voltage inputs on the control. Refer to Service Instructions
S280-42-1 NOVA Three-Phase Recloser Installation and
Operation Instructions for additional settinginformation.
Table 6. Receptacles and wiring; input and low voltage closing cables*
Description Catalog number
120 VAC low-voltage closing 2-pin input and 2-pin output receptacles KME4D-1775-A
120 VAC low-voltage closing with 3-pin input and 2-pin output receptacles KME4D-1775-B
120 VAC low-voltage closing with inlet hole and 2-pin output receptacle KME4D-1775-C
240 VAC low-voltage closing with 2-pin input and 2-pin output receptacle KME4D-1775-D
240 VAC low-voltage closing with 3-pin input and 2-pin output receptacle KME4D-1775-E
240 VAC low voltage closing, for 2-wire with inlet hole and 2-pin output receptacle KME4D-1775-F
240 VAC low-voltage closing, for 3-wire with inlet hole and 2-pin output receptacle KME4D-1775-G
120 VAC or 240 VAC input receptacle, 2-pin KME4D-1775-H
120 VAC input receptacle, 3-pin KME4D-1775-J
240 VAC input receptacle, 3-pin KME4D-1775-K
AC Input Cable, 120 or 240 VAC, 2-wire for 2-pin input for use with KME4D-1775-A, KME4D-1775-D, or KME4D-1775-H
receptacles. Replace X with desired length. Select from 10 to 80 feet.
KA11ME1-X
AC Input Cable, 240 VAC, 3-wire for 3-pin input for use with KME4D-1775-E or KME4D-1775-K receptacles. Replace X with
desired length. Select from 10 to 80 feet.
KME4-67-2-X
AC Input Cable, 120 VAC, 3-wire for 3-pin input for use with KME4D-1775-B and KME4D-1775-J receptacles. Replace X with
desired length. Select from 10 to 80 feet.
KME4-67-3-X
Low Voltage Closing Cable, 2-wire for use with KME4D-1775-A, KME4D-1775-B, KME4D-1775-C, KME4D-1775-D, KME4D-1775-E,
KME4D-1775-F, and KME4D-1775-G low voltage closing receptacles. Replace X with desired length. Select from 10 to 80 feet.
KA13ME1-X
*Low-voltage closing receptacles are only applicable to Eaton’s Cooper Power series auxiliary and line-powered reclosers with 14-pin connection (WE,WVE27,
WVE38X, VWE, VWVE27, VWVE38X, VSA12, VSA12B, VSA16, VSA20, VSA20A, VSO12, VSO16, NOVA15, NOVA27, NOVA38).
Table 7. Internal voltage sensing
Description Catalog number
Internal voltage sensing input receptacle, 4-pin KME4D-3799-A
ote:N Internal voltage sensing receptacle is only compatible
with reclosers equipped with internal voltage sensors.
ote:N The internal voltage sensing cable (KA97ME) is
ordered with the recloser. If a replacement cable is
required, contact your Eaton representative.
28 OPERATION INSTRUCTIONS MN280049EN September 2017
Form 4D Microprocessor-based pole-mount recloser control installation and operation instructions
