Page #6 background imageLoading...
Page #6 background image
Product information
Introduction
Service Information MN280049EN provides installation
and operation instructions for the Form 4D pole-mount
reclosercontrol.
Refer to Service Information S280-104-2 Form 4D
Microprocessor-Based Recloser Control Programming
Guide and S280-104-3 Form 4D Control Communications
Information for additional information.
Read this manual first
Read and understand the contents of this manual and follow
all locally approved procedures and safety practices before
installing or operating this equipment.
Additional information
These instructions cannot cover all details or vari ations
in the equipment, procedures, or process described, nor
provide directions for meeting every possible contin gency
during installation, operation, or maintenance. When
additional information is desired to satisfy a problem not
cov ered sufficiently for the user’s purpose, contact your
Eaton representative.
ANSI Standards
Eatons Cooper Power series reclosers are designed and
tested in accordance with applicable sections of the following
ANSI standards: C37.60 and C37.85 and ANSI Guide C37.61.
Quality standards
ISO 9001 Certified Quality Management System
Acceptance and initial inspection
Each Form 4D recloser control is completely assembled,
tested, and inspected at the factory. It is carefully calibrated,
adjusted and in good condition when accepted by the carrier
for shipment.
Upon receipt, inspect the carton for signs of damage.
Unpack the control and inspect it thoroughly for damage
incurred during shipment. If damage is discovered, file a
claim with the carrier immediately.
Handling and storage
Be careful during handling and storage of the control to
minimize the possibility of damage. If the control is to be
stored for any length of time prior to installation, provide a
clean, dry storage area. If storage is in a humid atmosphere,
make provisions to keep the control circuitry energized.
ote:N To energize the control, apply AC power to the AC
supply input terminal block located in the lower right
hand corner of the back panel of the control. Refer to
the Customer Connections for AC Power section in
this manual.
ote:N When opened, both the cabinet door and the inside
swing panel door lock into the open position. Lift
the door or swing panel up to raise the hinge out of
the locking position prior to closing the inside swing
panel door or the cabinet door.
Control battery storage and charging
The 24 VDC control battery in the Form 4D recloser control
is shipped in a charged state that is ready for use.
IMPORTANT
To maintain sufficient charge to operate the control
and prevent battery cell damage, the sealed lead-acid
batteries should be charged after no more than three
months of storage.
Temperature has an effect on battery life. Sealed
lead acid batteries should be stored, fully charged, at
room temperature. Avoid storing lead acid batteries at
temperatures exceeding 47°C (117°F), as damage can result
in approximately one month.
DANGER
Hazardous voltage. Do not connect potential
transformer low-voltage secondaries to the control
through cables or other wiring until the unit is installed
in the field. Transformer high-voltage primary windings
will become live when 120/240V AC is applied to the
control from an alternate source if the transformer
secondary is connected. Failure to comply may result in
severe personal injury or death.
T371.2
WARNING
Hazardous voltage. Before applying power to the control,
confirm that male pins of the input power receptacle are
electrically insulated to prevent unintentional contact
with 120/240V AC voltage. Failure to do so may result in
severe personal injury or death.
T372.1
To keep the battery charged, energize the control with AC
power applied to the user AC supply input connector block
TB1. See Customer Connections for AC Power. In addition, if
power to the control is not possible a separate portable charger
accessory is available. Catalog Number KA43ME7001 provides
a 120 Volt battery charger to power individual batteries.
IMPORTANT
Connect the control battery before AC power is
connected to the control’s AC supply Input Terminal
Block. The battery must be disconnected prior to
shipping or storing the control.
ote:N When shipped from the factory the battery will be in
the same carton as the control. The battery leads will
be taped to the battery casing. Connect the battery
plugs into the mating connectors to complete the
battery circuit.
1OPERATION INSTRUCTIONS MN280049EN September 2017
Form 4D Microprocessor-based pole-mount recloser control installation and operation instructions
