CAUTION
Control damage. De-energize both AC and DC power
prior to removing or installing any internal connections
or circuit boards in the control. Failure to comply can
result in damage to the control.
T241.1
1. Retain the control settings by uploading the settings
from the control. Refer to Upload Settings from Control
section in S280-104-2 Form 4D Control Programming
Guide for additional information.
2. Follow all locally approved safety procedures to remove
the control from service.
3. De-energize both AC and DC power.
A. Following established safety procedures, remove
AC input power from TB1 or from AC input
receptacle, if applicable.
B. Disconnect the control wiring to the battery(s)
(Figure 44).
4. Remove all wiring connections by unplugging each plug
assembly from the side of the module (Figure 47).
5. Loosen, but do not remove, the module swing panel
ground link 3/8” nuts with 3/8” nut driver (Figure 47).
6. Use a 1/4” nut drive to loosen, but not remove, the
three (3) nuts from the retaining bar (Figure 47).
7. Slide the retaining bar up to release the module.
8. Remove the module from the swing panel.
Install module
CAUTION
Equipment misoperation. Do not connect this control
to an energized recloser until all control settings have
been properly programmed and verified. Refer to the
programming information for this control. Failure to
comply can result in control and recloser misoperation,
equipment damage, and personal injury.
G110.3
1. Align the bottom lip of the module with the lower edge
of the swing panel.
2. Position the ground link on the swing panel to line up
with the ground lug on the module as it moves into
position (Figure 49).
3. Lift up on the module until the ground link slides into
place and continue lifting up until the module is firmly
back into the swing panel.
4. Press into place as necessary.
5. Slide the retaining bar down all the way over the
module’s aluminum extrusion as much as possible.
6. Torque the three (3) nuts to 24 in.-lbs. (Figure 47).
7. Torque the nuts on the ground link to 24 in.-lbs.
8. Reconnect all wire connections to the side of
the module.
9. Reconnect the battery (if used).
10. Reconnect AC input power to TB1 or to AC input
receptacle, if applicable.
11. Verify the module powers up properly.
12. Download the desired settings to the control.
13. Verify control operation before returning to service. Refer
to Before Placing Recloser and Control into Service
procedure in this manual for additional information.
Additional information
CAUTION
This equipment requires routine inspection and
maintenance to ensure proper operation. If it is not
maintained, it can fail to operate properly. Improper
operation can cause equipment damage and possible
personal injury.
G105.1
Replacement kits
Replacement kits for the Form 4D pole-mount control
are available through the factory Service Department.
To order these kits, refer to the Replacement Parts
price list for catalog numbers and pricing. Contact your
Eaton representative for additional information and order
procedures.
Factory-authorized service centers
Factory-authorized service centers are located throughout
the continental United States to provide maintenance,
repair and testing services for Eaton’s Cooper Power series
controls and reclosers. For further information, contact your
Eaton representative.
Type MET Recloser control tester
Versatile tool to check basic operation of the control
including minimum trip, TCC curve operation, fault
sequence, reclosing times, reset times.
ote:N MET tester is for basic operation testing and not to
be used for determining TCC coordination and other
precise measurements.
46 OPERATION INSTRUCTIONS MN280049EN September 2017
Form 4D Microprocessor-based pole-mount recloser control installation and operation instructions
