Battery test and charging procedures
Test procedure for installed battery
View battery information and test battery operation as
follows:
1. Scroll down the front panel HMI to the BATTERY menu
item and press the ENTER button. Code 081 Battery
Voltage and Current will be displayed:
VBat = XX.XX Volts
IBat = -X.XX Amps
2. Press the down arrow button to scroll to the Test
Battery command. Press the ENTER button.
The following message will appear: 082 Test Battery
(CONFIRM).
ote:N The battery cannot be tested when the control is
powered from the battery only (no AC power). If a
battery test is attempted with battery power only,
the test results will display as ATTENTION – 4
(Battery Test Blocked).
3. Press the ENTER key. The (TESTING...) message will
appear. The test duration is approximately five seconds.

If the battery is OK, the (PASS) message will appear.

If the battery is not OK, one of these messages will
appear:
“ATTENTION – 1” indicates Battery Test Trouble*
“ATTENTION – 2” indicates Battery Test Failed
“ATTENTION – 3” indicates Battery Test
Currently Running
“ATTENTION – 4” indicates Battery Test Blocked**
4. The battery test results can be viewed by pressing the
down arrow. The following information will be displayed:
VBat = XX.XX Volts
IBat = -X.XX Amps
Alarm condition:

During a battery test a 5Ω, 55 watt resistor is placed
across the battery terminals for approximately 5 seconds.
The Form 4D control measures the battery voltage, if
the voltage drops below 22.8 VDC the BATTERY LED
illuminates (Figure 43) and a battery alarm is issued, if
configured, at the end of the test.
DATA PORTS
ENTER
EDIT
ESC
PHASE FAULT
A B C
GROUND FAULT
ABOVE MIN TRIP
LOCKOUT
OPEN
CLOSED
VOLTAGE TRIP
FREQUENCY TRIP
SENSITIVE GND
A B C
X Y Z
PHASE VOLTAGE
ALARM
BATTERY
AC POWER
CONTROL OK
ALT
PROFILE 1
GND TRIP
BLOCKED
NON
RECLOSE
SUPER-
VISORY
OFF
HOT LINE
TAG
TRIP
OFF
(LOCKOUT)
CLOSE
Figure 43. Battery alarm LED.
Test procedure for uninstalled battery
The entire process should be conducted in a clean
environment, such as a repair shop.
Refer to Table 16 and follow this procedure to perform a
bench test on a control battery in a service shop:
1. Remove the control from service. Refer to Remove the
Control from Service procedure within the Testing
section of this manual.
2. Remove the battery from the control and carefully
transport it to a suitable service facility.
3. Measure battery voltage.
4. Apply test load and measure battery voltage after
5seconds of load to determine voltage drop. Refer to
Table 16 for Bench Test Load Condition.
5. Remove test load.
If the battery fails the test or is at least four years old, it
should be replaced. Refer to Table 16 for battery catalog part
numbers.
Table 16. Control battery bench testing and replacement information
Control type Battery
Battery
catalog
part # Voltage Type Amp/Hour
Bench
test load
condition
for 5 sec.
Acceptable
voltage drop
at end of
test load
Form 4D Pole-Mount
(standard capacity)
Hawker
Cyclon
KME4-215 24v Lead
Acid
8 5Ω
55 watt
3v
or less
Form 4D Pole-Mount
(high capacity)
Hawker
Genesis
KME5-134-1 24v (two 12v
batteries)
Lead
Acid
13 5Ω
55 watt
2v
or less
* Battery Test Trouble indicates that the test results were not lower than
battery failure voltage (15V) and not higher than the test voltage (22.8V).
** Battery Test Blocked indicates a battery test was attempted with battery
power only. The battery cannot be tested when the control is powered
from the battery only (no AC power).
42
OPERATION INSTRUCTIONS MN280049EN September 2017
Form 4D Microprocessor-based pole-mount recloser control installation and operation instructions
