22MAINTENANCE INSTRUCTIONS MN280064EN October 2017
Operator cabinet (Figure 25)
Item no. Description Catalog number
Qty. per
assy.
Cabinet assembly, complete
(includes items 1 thru 11)
KA154VS4 1
1 Cabinet only KA133VSM 1
2 Gasket KP2084A7 1
3 Latch assembly KA152VS 1
4
Machine screw, flat
hd, #10-24 x 3/4, stl
K721601110075Z 1
5 Spacer KP3006A32 1
6 Flat washer K90020101000Z 1
7 Bushing KP3041A5 1
8 Handle assembly KP153VS 1
9 Vent plug KP2204A1 2
10 Window KP1240M 2
11 Speed nut KP2005A1 8
12 Gasket KP2084A19 1
13 Machine screw, hex
hd,1/2-13 x 1, st stl
K730115150100A 1
14 Washer KP2090A102 1
15 Nut, hex, 1/2-13, st stl K880215113050A 2
16 Spacer KP3011A132 2
17 Fuse clip KP1091ME1 2
18 Fuse KP2075A22 2
19 Nut, hex, #8-32, st stl K880215132008A 2
20 Lockwasher, #8, st stl K900815008000A 2
21 Heater assembly for
Operator cabinet. KVSO125VA 1
Resistor, 500 ohm, 50
watt, IRC
K999904310084A 2
Toggle switch, DPST K999904250091A 1
Decal KP207VR 1
Fuse holder KP2074A1 2
Fuse, Type AGC, 1A-250V KP2075A2 2
Item no. Description Catalog number
Qty. per
assy.
22 Nut, hex, #8-32, st stl K880215132008A 2
23 Lockwasher, #8, med, st stl K900815008000A 2
24 Spring KP1215VSM 1
25 Elastic stop nut KP2020A6 2
26 Washer KP2090A39 2
27
Machine screw,
rd hd, #6-32 x 3/8, brass K721525106037A 2
28 Flat washer, #6, st stl K900215006000A 2
29 Spacer KP3017A2 1
30 Lockwasher, 1/2, med, st stl K900815050000A 1
31 Crank assembly KA134VSM2 1
32 Spacer KP3013A61 2
33 Hex nut, 1/4-20, stl K880201120025Q 2
34 Lockwasher, 1/4, med, stl K900801025000Z 2
THE FOLLOWING PARTS
ARE APPLICABLE TO THE
BCT ACCESSORY ONLY
35 Terminal block KP2101A53 3
36
Machine screw,
rd hd, #8-32 x 1/2, brass K721525108050A 3
37
Machine screw,
rd hd, #10-24 x 1-1/8, stl K721501110106A 6
38 Lockwasher, ext tooth, #10, stl K901101010000Z 6
39 Hex nut, #10-24, stl K881001124010Z 6
40 Panel KP1098VSM 1
41 Machine screw,
rd hd, 1/4-20 x 1/2, stl
K721501125050Z 2
42
Lockwasher, 1/4, split,
med, stl K900801025000Z 2
43 Hex nut, 1/4-20, stl K881001120025Z 2
