Type VSA12, VSA16 and VSA20/800 maintenance instructions
24MAINTENANCE INSTRUCTIONS MN280064EN October 2017
Terminal Panel (Figure 26)
Item no. Description Catalog number
Qty. per
assy.
1 Terminal strip KP2101A56 1
2
Machine screw,
rd hd, #6-32 x 5/8, stl
K721515106062A 2
3
Lockwasher, #6,
external tooth, stl
K901115006000A 2
4 Hex nut, #6-32, stl K881015132006A 4
5 Marker strip KP2076A51 1
6 Marker strip KP2101A256 1
7 Capacitor assembly KA256VS 1
8 Capacitor KA158CE 3
9 Silicon diode KP4011A9 3
10 Resistor KP4022A31 3
11 Rivet, 0.146 x 9/32, stl K930801014028Z 6
12 Flat washer, #6, brass K900525014031A 6
13 Bracket and socket assembly KA189VSM2 1
14 Machine screw,
rd hd #10-24 x 3/8, stl
K721515110037A 1
15
Lockwasher, #10 external
tooth, stl
K901115010000A 2
16 Hex nut, #10-24, stl K881015124010A 2
17 Capacitor assembly KA964M11 1
18 Machine screw,
rd hd, #8-32 x 3/8, stl
K721515108037A 2
19
Lockwasher, #8, external
tooth, stl
K901115008000A 2
Item no. Description Catalog number
Qty. per
assy.
20 Hex nut, #8-32, stl K881015132008A 4
21 Fuse box KP2261A1 1
22 Machine screw,
rd hd, #10-24 x 1-3/8
K721515110137Q 2
23 Tapping block KP1287VS 1
24 Strap KP1286VS 1
25 Machine screw,
rd hd, #10-24 x 5/8
K721515110063A 1
26 Lockwasher, #10, stl K900815010000A 2
27 Fuse, Bussmann Type FRN-R2 KP2075A22 2
28 Panel Board KP1077VSM 1
29 Spacer KP3013A23 3
30 Spacer KP3010A4 1
31 Hex nut, #10-24, brass K881025124010A 4
32 Lockwasher, #10, med, brass K900830010000A 4
33 Flat washer, #10, brass K900525020043A 4
34 Control cable assembly KA106VS 1
35 Terminal block KP2101A27 1
36 Label KP1144VSM 1
37 Cable receptacle KP2056A5 1
38 Screw, self tapping,
#6-32 x 3/8
K751515106037A 4
39 Lock washer, #6, medium, stl K900815006000A 4
