Eaton GridAdvisor Series II Maintenance Instructions

Type VSA12, VSA16 and VSA20/800 maintenance instructions
27 MAINTENANCE INSTRUCTIONS MN280064EN October 2017
Operating mechanism electrical parts (Figure 28)
Item no. Description Catalog number
Qty. per
Assy.
1 Lever KP1029VS 1
2 Roll pin, 3/32 x 3/4, stl K970801043075M 1
3 Switch, 2 DPST 152/ 152/a2 KA612R24 1
4 Machine screw,
rd hd, #10-24 x 2-3/4, stl
K721501110275Z 2
5 Split lockwasher, med, #10, stl K900801010000Z 2
6 Spacer KP3009A167 2
7 Trip solenoid 152/TC KA1055M1 1
8
Machine screw,
rd hd, #10-24 x 5/16, stl
K721501110031Z 4
9 Split lockwasher, med, #10, stl K900801010000Z 4
10 Plain washer, #10, brass K900525020043A 4
11 Solenoid stop KP1092CE 1
12 Machine screw,
rd hd, #10-24 x 5/16, stl
K721501110031Z 1
13 Split lockwasher, med, #10, stl K900801010000Z 1
14 Closing circuit switch 152/bb1 KP2181A8 1
15 Spacer KP3006A56 2
16 Machine screw,
rd hd, #6-32 x 1, stl
K721501106100Z 2
17 Split lockwasher, med, #6, stl K900801006000Z 2
18 Motor circuit switch 152/aa1 KA1230VS 1
19 Machine screw,
rd hd, #6-32 x 7/8, stl
K721501106087Z 2
20 Split lockwasher, med, #6, stl K900801006000Z 2
21 Terminal strip KP2101A1 1
22 Machine screw,
rd hd, #6-32 x 1/2, stl
K721501106050Z 2
23 Split lockwasher, med, #6, stl K900801006000Z 2
24 Closing solenoid 152/CC KA169VSM1 1
25 Solenoid stop KP1163VSM 1
26 Machine screw,
rd hd, #10-24 x 3/4, stl
K721501110075Z 1
27 Split lockwasher, med, #10, stl K900801010000Z 1
28 Spacer KP3006A1 1
29 Machine screw,
rd hd, #10-24 x 3/8, stl
K721501110037Z 2
30 Split lockwasher, med, #10, stl K900801010000Z 2
31 Machine screw
rd hd, #10-24 x 5/16, stl
K721501110031Z 2
Item no. Description Catalog number
Qty. per
Assy.
32 Split lockwasher, med, #10, stl K900810010000Z 2
33 Plain washer, #10, brass K900525020043Z 2
34 Manual close switch 152/MCS KA2181A8 1
35 Machine screw,
rd hd, #6-32 x 7/8, stl
K721501106087Z 2
36 Split lockwasher, med, #6, stl K900801006000Z 2
37 Manual limit switch 152/LS1 KA201CE 1
38 Insulating barrier KP1244VSM 1
39 Machine screw,
rd hd, #4-40 x 1/2, stl
K721501104050Z 2
40 Split lockwasher, med, #4, stl K900801004000Z 2
41 Spring position switch
152/SP1 152/SP2
KP2181A8 2
42 Insulating barrier KNC1070S 1
43 Spacer KP3007A32 2
44 Machine screw,
rd hd, #6-32 x 2, stl
K721201106200Z 2
45 Split lockwasher, med, #6, stl K900801006000Z 2
46 Auxiliary switch, 4 NO - 4 NC KA612R44 1
47 Lever KVS01036V1 1
48 Roll pin, 3/32 x 3/4, stl K970801093075M 1
49 Spacer KP3009A90 2
50 Machine screw,
rd hd, #10-24 x 3-3/4, stl
K721501110375Z 2
51 Split lockwasher, med, #10, stl K900801010000Z 2
52 Spacer KP1020VS 2
53 Machine screw,
flt hd, #10-24 x 7/8, stl
K721601110082Z 2
54 Terminal strip KP2101A18 1
55 Marker strip KP2101A218 1
56 Machine screw,
rd hd, #10-24 x 5/8, stl
K721501110062Z 2
57 Split lockwasher, med, #10, stl K900801010000Z 2
58 Hex nut, #10-24, stl K881001124010Z 2
59 Bracket KP1099VSM 1
60 Hex nut, #8-32, stl K881001132008Z 2
61 Split lockwasher, med, #8, stl K900801008000Z 2
62 Plain washer, #8, stl K900201008000Z 2
