Eizo FlexScan S2202W User Manual

28
Chapter 5 Reference
5-2 Specications
LCD Panel 22-inch (560 mm) TFT color LCD with anti-glare
Viewing angle: Horizontal 170°, Vertical 160° (CR:10 or more)
Dot Pitch 0.282mm
Horizontal Scan Frequency Analog: 31-82kHz
Digital: 31-65kHz
Vertical Scan Frequency Analog: 55-76Hz (Non-interlace)
(1680 × 1050: 55-61Hz)
Digital: 59-61Hz (Non-interlace)
(VGA TEXT: 69-71Hz)
Resolution 1680 dots × 1050 lines
Max. Dot Clock Analog: 150MHz
Digital: 120MHz
Max. Display Color Approx. 16.77 million colors: Applicable to 8 bit (1064.33 million colors/
10bit LUT)
Display Area (H × V) 473.8mm × 296.1mm
Power Supply 100-120 VAC ±10%, 50/60Hz 0.85A
200-240 VAC ±10%, 50/60Hz 0.5A
Power
Consumption
Screen Display On 51W or less (Speaker working)
47W or less (Speaker not working)
Power saving mode 0.7W or less (for single signal input, when stereo mini jack cable is not
connected)
Power button Off 0.5W or less (when stereo mini jack cable is not connected)
Main Power switch
Off
0W
Input Signal Connector DVI-D connector (Applicable to HDCP), D-Sub mini 15-pin
Analog Input Signal (Sync) Separate, TTL, positive/ negative
Composite, TTL, positive/ negative
Analog Input Signal (Video) Analog, Positive (0.7Vp-p/75Ω)
Digital Signal Transmission System TMDS (Single Link)
Video Signal Memory Analog signal: 45 (preset: 17)
Digital signal: 10
Audio Output Speaker output: 0.5W + 0.5W (8Ω, THD: 10% or less)
Headphone output: 2mW + 2mW
Line input Input impedance : 48 kΩ (typ.)
Input level :1.0 Vrms (Max.)
Plug & Play VESA DDC 2B / EDID structure 1.3
Dimensions
(Width) × (Height) ×
(Depth)
Main unit (including
Height adjustable
stand)
507 mm (20.0 inch) × 439 - 521 mm (17.3 - 20.5 inch) × 208.5 mm
(8.2 inch)
Main unit (including
Tilt stand)
507 mm (20.0 inch) × 415 mm (16.3 inch) × 205 mm (8.1 inch)
Main unit (including
EZ-UP stand)
507 mm (20.0 inch) × 351.5 - 516.5 mm (13.8 - 20.3 inch) × 279.9 mm -
296.4 mm (11.0 - 11.7 inch)
Main unit (without
stand)
507 mm (20.0 inch) × 333 mm (13.1 inch) × 74 mm (2.9 inch)
